Omron G9SX Series User Manual

G9SX
5
Model Number Structure
Model Number Legend
1. Functions
AD/ADA: Advanced Unit
BC: Basic Unit
EX: Expansion Unit
2. Output Configuration (Instantaneous Safety Outputs)
0: None
2: 2 outputs
3: 3 outputs
4: 4 outputs
3. Output Configuration (OFF-delayed Safety Outputs)
0: None
2: 2 outputs
4: 4 outputs
4. Output Configuration (Auxiliary Outputs)
1: 1 output
2: 2 outputs
5. Max. OFF-delay Time
Advanced Unit
T15: 15 s
T150: 150 s
Basic Unit
No indicator: No OFF delay
Expansion Unit
No indicator: No OFF delay
T: OFF delay
6. Terminal Block Type
RT: Screw terminals
RC: Spring-cage terminals
Ordering Information
List of Models
Advanced Unit
*1. The OFF-delay time can be set in 16 steps as follows:
T15: 0/0.2/0.3/0.4/0.5/0.6/0.7/1/1.5/2/3/4/5/7/10/15 s
T150: 0/10/20/30/40/50/60/70/80/90/100/110/120/130/140/150 s
*2. The OFF-delayed output becomes an instantaneous output by setting the OFF-delay time to 0 s.
*3. P channel MOS-FET output
*4. PNP transistor output
Basic Unit
*1. P channel MOS-FET output
*2. PNP transistor output
Expansion Unit
*1. PNP transistor output
*2. The OFF-delay time is synchronized to the OFF-delay time setting in the connected Advanced Unit (G9SX-AD-@/G9SX-ADA-@).
12 5 634
G9SX-@@@@@@-@@@-@@
Note: Please see “Ordering Information” below for the actual models that can be ordered.
Safety outputs *3
Auxiliary
outputs *4
Logical AND
connection
No. of
input
channels
Max.
OFF-delay
time *1
Rated
voltage
Terminal block
type
Model
Instantaneous
OFF-delayed
*2
Inputs Outputs
3
(Semiconductor)
2
(Semiconductor)
2
( Semiconductor)
1
(Semi-
conductor)
1
(Semi-
conductor)
1 or 2
channels
15 s
24 VDC
Screw terminals G9SX-AD322-T15-RT
Spring-cage
terminals
G9SX-AD322-T15-RC
150 s
Screw terminals G9SX-AD322-T150-RT
Spring-cage
terminals
G9SX-AD322-T150-RC
2
(Semiconductor)
2
(Semi-
conductor)
2
(Semi-
conductor)
15 s
Screw terminals G9SX-ADA222-T15-RT
Spring-cage
terminals
G9SX-ADA222-T15-RC
150 s
Screw terminals G9SX-ADA222-T150-RT
Spring-cage
terminals
G9SX-ADA222-T150-RC
Safety outputs *1
Auxiliary outputs
*2
No. of input
channels
Rated voltage Terminal block type Model
Instantaneous OFF-delayed
2 --- 2 (Semiconductor)
1 or 2
channels
24 VDC
Screw terminals G9SX-BC202-RT
Spring-cage terminals G9SX-BC202-RC
Safety outputs
Auxiliary outputs
*1
OFF-delay
time
Rated voltage Terminal block type Model
Instantaneous OFF-delayed
4 PST-NO ---
1 (Semiconductor)
---
24 VDC
Screw terminals G9SX-EX401-RT
Spring-cage terminals G9SX-EX401-RC
--- 4 PST-NO *2
Screw terminals G9SX-EX041-T-RT
Spring-cage terminals G9SX-EX041-T-RC

Omron G9SX Series Specifications

General

Response time	≤ 14 ms
Supply voltage	24 VDC
Reset function	Automatic or manual
Standards	ISO 13849-1
Operating temperature	55 °C
