H3BG
H3BG
303
Nomenclature
H3BG-8/H3BA-8(H)
H3BG-F/H3BG(-FH)
Dial Digit Display Windows
Delta Operation
Indicator
Star-delta Transfer Time
Display Window
Rated Star Time Selector
Star Operation Indicator
Star-delta Transfer Time
Selector
Rated Voltage Classification Color Code
Dial Digit Display Windows
Delta Operation Indicator
Star-delta Transfer Time
Display Window
Rated Star Time Selector
Star Operation Indicator
Star-delta Transfer Time
Selector
Rated Voltage Classification Color Code
Operation
Timing Chart
Note: 1. The terminal numbers in parentheses apply to H3BG-F(H).
2. Instantaneous contact is only available for H3BG-8H and
H3BG-FH.

Omron H3CR-A Specifications

General

Time Range	0.05 seconds to 300 hours
Output Type	Relay
Mounting Type	DIN Rail
Operating Temperature	-10°C to 55°C
Contact Form	SPDT
Number of Pins	8
Contact Rating	5A at 250VAC
Storage Temperature	-25°C to 65°C
Type	Solid State Timer
Dimensions	48 mm x 48 mm
Operating Mode	ON-delay, OFF-delay, Interval, One-shot
Operating Voltage	24V DC, 100-240V AC
