Omron H3CR-A8E - Model Number Legend

H3CR-A
H3CR-A
5
8-pin Models
Output Supply voltage Input type T ime range Operating mode
(see note 2)
Model
Contact
100 to 240 V AC (50/60 Hz)/
100 to 125 VDC
No-input
available
0.05 s to 300 h Four multi-modes: A,
B2, E, J
(P l t t)
H3CR-A8
24 to 48 V AC (50/60 Hz)/
12 to 48 VDC
,,
(Power supply start)
100 to 240 V AC (50/60 Hz)/
100 to 125 VDC
0.1 s to 600 h H3CR-A8-301
24 to 48 V AC (50/60 Hz)/
12 to 48 VDC
Transistor
(Photocoupler)
24 to 48 V AC (50/60 Hz)/
12 to 48 VDC
0.05 s to 300 h
H3CR-A8S
T ime-limit contact
and instantaneous
tt
100 to 240 V AC (50/60 Hz)/
100 to 125 VDC
H3CR-A8E
contact
24 to 48 VDC/V AC (50/60 Hz)
Note: 1. Specify both the model number and supply voltage when ordering.
Example: H3CR-A 100 to 240 V AC (50/60 Hz)/100 to 125 VDC
Supply voltage
2. The operating modes are as follows
A: ON-delay D: Signal OFF-delay
B: Flicker OFF start E: Interval
B2: Flicker ON start G: Signal ON/OFF-delay
C: Signal ON/OFF-delay
J: One-shot
Model Number Legend:
H3CR-Ajjj-j
123 4
1. Number of Pins
None: 1 1-pin models
8: 8-pin models
2. Input T ype for 1 1-pin Models
None: No-voltage input (NPN type)
P: V oltage input (PNP type)
3. Output
None:
Relay output (DPDT)
S: Transistor output (NPN/PNP universal use)
E: Relay output (SPDT) with instantaneous relay output
(SPDT)
4. Suffix
300: Dual mode models (signal ON/OFF-delay and one-shot)
301: Double time scale (range) models (0.1 s to 600 h)
