8-pin, finger safe type
P3G-08 with Y92A-48G (see note 1)
11-pin P3GA-11
1
1-pin, finger safe type
P3GA-1
1 with Y92A-48G (see note 1)
T
ime Setting Ring
Setting a specific time
Y92S-27
Limiting the setting range
Y92S-28
Panel Cover (see note 2)
Light gray (5Y7/1)
Y92P-48GL
Black (N1.5)
Y92P-48GB
Medium gray (5Y5/1)
Y92P-48GM
Hold-down Clip (see note 3)
For PL08 and PL1
1 Sockets
Y92H-7
For PF085A Socket
Y92H-8
Note: 1.
Y92A-48G is a finger safe terminal cover which is attached to the P3G-08 or P3GA-1
1 Socket.
2.
The T
ime Setting Ring and Panel Cover are sold together
.
3.
Hold-down Clips are sold in sets of two.
Specifications
General
Item H3CR-A/-AS H3CR-AP H3CR-A8/-A8S H3CR-A8E
Operating
mode
A: ON-delay
B: Flicker OFF start
B2: Flicker ON start
C:
Signal ON/OFF-delay
D:
Signal OFF-delay
E: Interval
G: Signal ON/OFF-delay (Only for H3CR-A-300)
J: One-shot (Only for H3CR-A-300)
A: ON-delay (power supply start)
B2: Flicker ON start (power supply start)
E:
Interval (power supply start)
J: One-shot (power supply start)
Pin type
11-pin 8-pin
Input type
No-voltage input
V
oltage input
---
T
ime-limit output
type
H3CR-A/-A8/-AP:
Relay output (DPDT)
H3CR-AS/-A8S: Transistor output (NPN/PNP universal)*
Relay output (SPDT)
Instantaneous output
type
---
Relay output (SPDT)
Mounting method
DIN track mounting, surface mounting, and flush mounting
Approved standards
UL508, CSA C22.2 No.14, NK, Lloyds
Conforms to EN61812-1 (VDE0435/P2021), IEC60664-1 (VDE01
10) 4kV/2, EN60947-5-1 (for contact output),
and EN60947-5-2 (for non-contact output).
*The internal circuits are optically isolated from the output. This enables universal application as NPN or PNP transistor
.
