H7CX-A@-N
11
Dimensions with Flush Mounting Adapter
48 × 48
44.8 × 44.8
59
6
H7CX-AD-N/-ASD-N/-AWSD-N/-A4D-N/-A4SD-N/-A4WSD-N (Flush Mounting Models)
Note: M3.5 terminal screw (effective length: 6 mm)
48 × 48
44.8 × 44.8
63.7
14.4
6
H7CX-A11-N/-A11S-N/-A11D1-N/-A11SD1-N/-A114-N/-A114S-N/-A114D1-N (Flush Mounting/Surface Mounting Models)
58
48
76.57.5
Panel
Y92F-30 (provided)
Flush Mounting Adapte
Y92S-29 (provided)
Waterproof Packing
(51)
H7CX-A-N/-AS-N/-AW-N/-AWS-N/-AWD1-N/-AWSD1-N/-A4-N/-A4S-N/-A4W-N
(Provided with Adapter and Waterproof Packing)
Panel Cutouts
Panel cutouts are as shown below. (according
to DIN43700).
Note: 1. The mounting panel thickness
should be 1 to 5 mm.
2.
To allow easier operation, it is
recommended that Adapters be mounted
so that the gap between sides with hooks
is at least 15 mm (i.e., with the panel
cutouts separated by at least 60 mm).
3.
It is possible to horizontally mount
Timers side by side. Attach the Flush
Mounting Adapters so that the surfaces
without hooks are on the sides of the
Timers. If they are mounted side-by-
side, water-resistance will be lost.
Dimensions with Front
Connecting Socket
* These dimensions depend on the kind of DIN Track.
(Reference value)
60 min.
60 min.
15 min.
45
+
0.6
0
45
+
0.6
0
A
With Y92A-48F1 attached.
With Y92A-48 attached.
A=(48n−2.5)
+1
−0
A=(51n−5.5)
+1
−0
A={48n−2.5+(n−1)×4}
+1
−0
n Units mounted
side by side
103.2*
100.9
H7CX
-A11@
P2CF-11(-E) Front Connecting Socket
(order separately)
58
48
(51)
7.5 57.5
Panel
Y92F-30 (provided)
Flush Mounting Adapter
Y92S-29 (provided)
Waterproof Packing
H7CX-AD-N/-ASD-N/-AWSD-N/-A4D-N/-A4SD-N/-A4WSD-N
(Provided with Adapter and Waterproof Packing)
58
48
(51)
7.5 89.9
Panel
P3GA-11 (order separately)
Back-connecting Socket
Y92F-30 (order separately)
Flush Mounting Adapter
Y92
-29 (order separately)
Waterproof Packing
H7CX-A11-N/-A11S-N/-A11D1-N/-A11SD1-N/-A114-N/-A114S-N/-A114D1-N
(Adapter and Waterproof Packing Ordered Separately)
To Next Page
