Self-powered Total Counter
H7EC
C-11
Counters
■
Characteristics
Note:
Weight includes waterproof packing and flush mounting bracket.
■
Reference Value
Item H7EC-NV-
@
H7EC-NV-
@
H
H7EC-NFV-
@
H7EC-N-
@
Insulation resistance
100 M
Ω
min. (at 500 VDC) between
current-carrying metal parts and ex-
posed non-current-carrying metal parts,
and between the backlight power sup-
ply terminal and count input terminals/
reset terminals for backlight models
100 M
Ω
min. (at 500 VDC) between
current-carrying metal parts and ex-
posed non-current-carrying metal parts
and between count input terminals and
reset terminals
100 M
Ω
min. (at 500 VDC) between
current-carrying metal parts and ex-
posed non-current-carrying metal parts
Dielectric strength
1,000 VAC, 50/60 Hz for 1 min between
current-carrying metal parts and ex-
posed non-current-carrying metal parts
and between the backlight power sup-
ply terminal and count input terminals/
reset terminals for backlight models
3,700 VAC, 50/60 Hz for 1 min between
current-carrying metal parts and ex-
posed non-current-carrying metal parts
2,200 VAC, 50/60 Hz for 1 min between
reset terminals and exposed non-cur-
rent-carrying metal parts and between
count input terminals and reset termi-
nals
1,000 VAC, 50/60 Hz for 1 min between
current-carrying metal parts and ex-
posed non-current-carrying metal parts
Impulse withstand
voltage
4.5 kV between current-carrying termi-
nal and exposed non-current-carrying
metal parts
4.5 kV between current-carrying termi-
nal and exposed non-current-carrying
metal parts
3 kV between input terminals and reset
terminals
4.5 kV between current-carrying termi-
nal and exposed non-current-carrying
metal parts
Noise immunity
Square-wave noise generated by noise simulator (pulse width: 100 ns/1
µ
s, 1-ns rise)
±
600 V (Between count input terminals/
Between reset terminals)
±
480 V (Between the backlight power
supply terminals for backlight models)
±
1.5 kV (Between count input termi-
nals)
±
500 V (Between reset terminals)
±
500 V (Between count input terminals/
Between reset terminals)
Static immunity
±
8 kV (malfunction)
Vibration resistance
Malfunction: 0.15-mm single amplitude at 10 to 55 Hz for 10 min each in 3 directions
Destruction: 0.375-mm single amplitude at 10 to 55 Hz for 2 hrs each in 3 directions
Shock resistance
Malfunction: 200 m/s
2
3 times each in 6 directions
Destruction: 300 m/s
2
3 times each in 6 directions
EMC
(EMI) EN61326
Emission Enclosure: EN55011 Group 1 class B
(EMS) EN61326
Immunity ESD: EN61000-4-2: 4 kV contact discharge (level 2)
8 kV air discharge (level 3)
Immunity RF-interference from AM Radio Waves:
EN61000-4-3: 10 V/m (80 MHz to 1 GHz) (level 3)
Immunity RF-interference from Pulse-modulated Radio Waves:
EN61000-4-3: 10 V/m (900 MHz
±
5 MHz) (level 3)
Immunity Conducted Disturbance: EN61000-4-6: 10 V (0.15 to 80 MHz) (level 3)
Immunity Burst: EN61000-4-4: 2 kV power line (level 3)
2 kV I/O signal line (level 4)
Degree of protection
Front panel: IP66, NEMA4
Terminal block: IP20
Weight (see note)
No-backlight model: Approx. 60 g
Backlight model: Approx. 65 g
Approx. 60 g Approx. 60 g
Item Value Note
Battery life 7 years min. with continuous input at 25
°
C
(lithium battery)
The battery life is calculated according to the conditions in the left column and
therefore is not a guaranteed value. Use these value as reference for mainte-
nance or replacement.

Omron H7EC Specifications

General

Model	H7EC
Display Type	LCD
Digits	8
Digit Height	8.6 mm
Operating Temperature	-10 to 55°C
Weight	Approx. 50 g
Power Supply	Battery
Mounting	Panel Mount
Input Type	Contact
Reset Method	Manual
Dimensions	48 x 24 x 45 mm
Counting Speed	30 Hz
