10
Names and Functions of the Components
Rear
Elbow rest
The elbow is placed here before
measurement starts.
[POWER] switch
AC connector
Fuse
The provided power cord plugs into this connector.
(Page 12)
A fuse has been installed.
Turns the power on/off.
RS-232C connector
Enables connection to a computer.
[PRINT] switch
Selects whether or not results are
printed.
SD memory card connector
An SD memory card can be inserted in
this connector.
