2-19
List of Settings Section 2
List of
Settings
Prescale Level
Note The values beginning with H' in the Monitor/Setting range column are used when setting or monitor-
ing data via communications.
Variable
type
Address Parameter
name
Charac-
ter
Monitor/Setting range Character Default
setting
Decimal point Unit
C7 0000 Prescale 0X ps0. ax H’00000000 to H’0001869F: (0.0000 to 9.9999) 0. 0000 to 9. 9999 1. 0000 4---
0001 Prescale 0Y ps0. ay H’FFFFFFF7 to H’00000009: (−9 to 9) 10 -9 to 10 9 10 0 --- ---
0004 Decimal point
position 0
dp0 H’00000000 to H’00000004: (0 to 4) \\\\\, \\\\. \,
\\\. \\, \\. \\\,
\. \\\\
\\\\\ --- ---
0005 Prescale 1X ps1. ax H’00000000 to H’0001869F: (0.0000 to 9.9999) 0. 0000 to 9. 9999 1. 0000 4---
0006 Prescale 1Y ps1. ay H’FFFFFFF7 to H’00000009: (−9 to 9) 10 -9 to 10 9 10 0 --- ---
0009 Decimal point
position 1
dp1 H’00000000 to H’00000004: (0 to 4) \\\\\, \\\\. \,
\\\. \\, \\. \\\,
\. \\\\
\\\\\ --- ---
000A Prescale 2X ps2. ax H’00000000 to H’0001869F: (0.0000 to 9.9999) 0. 0000 to 9. 9999 1. 0000 4---
000B Prescale 2Y ps2. ay H’FFFFFFF7 to H’00000009: (−9 to 9) 10 -9 to 10 9 10 0 --- ---
000E Decimal point
position 2
dp2 H’00000000 to H’00000004: (0 to 4) \\\\\, \\\\. \,
\\\. \\, \\. \\\,
\. \\\\
\\\\\ --- ---
000F Prescale 3X ps3. ax H’00000000 to H’0001869F: (0.0000 to 9.9999) 0. 0000 to 9. 9999 1. 0000 4---
0010 Prescale 3Y ps3. ay H’FFFFFFF7 to H’00000009: (−9 to 9) 10 -9 to 10 9 10 0 --- ---
0013 Decimal point
position 3
dp3 H’00000000 to H’00000004: (0 to 4) \\\\\, \\\\. \,
\\\. \\, \\. \\\,
\. \\\\
\\\\\ --- ---
0014 Prescale 4X ps4. ax H’00000000 to H’0001869F: (0.0000 to 9.9999) 0. 0000 to 9. 9999 1. 0000 4---
0015 Prescale 4Y ps4. ay H’FFFFFFF7 to H’00000009: (−9 to 9) 10 -9 to 10 9 10 0 --- ---
0018 Decimal point
position 4
dp4 H’00000000 to H’00000004: (0 to 4) \\\\\, \\\\. \,
\\\. \\, \\. \\\,
\. \\\\
\\\\\ --- ---
0019 Prescale 5X ps5. ax H’00000000 to H’0001869F: (0.0000 to 9.9999) 0. 0000 to 9. 9999 1. 0000 4---
001A Prescale 5Y ps5. ay H’FFFFFFF7 to H’00000009: (−9 to 9) 10 -9 to 10 9 10 0 --- ---
001D Decimal point
position 5
dp5 H’00000000 to H’00000004: (0 to 4) \\\\\, \\\\. \,
\\\. \\, \\. \\\,
\. \\\\
\\\\\ --- ---
001E Prescale 6X ps6. ax H’00000000 to H’0001869F: (0.0000 to 9.9999) 0. 0000 to 9. 9999 1. 0000 4---
001F Prescale 6Y ps6. ay H’FFFFFFF7 to H’00000009: (−9 to 9) 10 -9 to 10 9 10 0 --- ---
0022 Decimal point
position 6
dp6 H’00000000 to H’00000004: (0 to 4) \\\\\, \\\\. \,
\\\. \\, \\. \\\,
\. \\\\
\\\\\ --- ---
0023 Prescale 7X ps7. ax H’00000000 to H’0001869F: (0.0000 to 9.9999) 0. 0000 to 9. 9999 1. 0000 4---
0024 Prescale 7Y ps7. ay H’FFFFFFF7 to H’00000009: (−9 to 9) 10 -9 to 10 9 10 0 --- ---
0027 Decimal point
position 7
dp7 H’00000000 to H’00000004: (0 to 4) \\\\\, \\\\. \,
\\\. \\, \\. \\\,
\. \\\\
\\\\\ --- ---
To Next Page
