2-21
List of Settings Section 2
List of
Settings
Note The values beginning with H' in the Monitor/Setting range column are used when setting or monitor-
ing data via communications.
Linear Output Level
Note The values beginning with H' in the Monitor/Setting range column are used when setting or monitor-
ing data via communications.
C8 0015 Comparative set
value 54
s?5.o4 H’FFFFB1E1 to H’0001869F (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting.
---
0025 Comparative set
value 53
s?5.o3 H’FFFFB1E1 to H’0001869F (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting.
---
0016 Comparative set
value 52
s?5.o2 H’FFFFB1E1 to H’0001869F (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting.
---
0017 Comparative set
value 51
s?5.o1 H’FFFFB1E1 to H’0001869F (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting.
---
0018 Comparative set
value 65
s?6.o5 H’FFFFB1E1 to H’0001869F (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting.
---
0019 Comparative set
value 64
s?6.o4 H’FFFFB1E1 to H’0001869F (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting.
---
0026 Comparative set
value 63
s?6.o3 H’FFFFB1E1 to H’0001869F (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting.
---
001A Comparative set
value 62
s?6.o2 H’FFFFB1E1 to H’0001869F (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting.
---
001B Comparative set
value 61
s?6.o1 H’FFFFB1E1 to H’0001869F (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting.
---
001C Comparative set
value 75
s?7.o5 H’FFFFB1E1 to H’0001869F (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting
---
001D Comparative set
value 74
s?7.o4 H’FFFFB1E1 to H’0001869F (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting.
---
0027 Comparative set
value 73
s?7.o3 H’FFFFB1E1 to H’0001869F (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting.
---
001E Comparative set
value 72
s?7.o2 H’FFFFB1E1 to H’0001869F (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting.
---
001F Comparative set
value 71
s?7.o1 H’FFFFB1E1 to H’0001869F (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting.
---
Variable
type
Address Parameter
name
Charac-
ter
Monitor/Setting range Character Default
setting
Decimal point Unit
Variable
type
Address Parameter
name
Charac-
ter
Monitor/Setting range Character Default
setting
Decimal point Unit
C9 0000 Linear current
type
lset. c H’00000000: 0-20 mA (0), H’00000001: 4-20 mA (1) 0-20, 4-20 4-20 --- ---
0001 Linear voltage
type
lset. v H’00000000: 0-5 V (0), H’00000001: 1-5 V (1),
H’00000002: 0-10 V (2)
0-5, 1-5, 0-10 1-5 --- ---
0002 Linear output
upper limit
lset.
h H’FFFFB1E1 to H’0001869F (−19999 to 99999) :9999 to 99999 99999 --- ---
0003 Linear output
lower limit
lset.
l H’FFFFB1E1 to H’0001869F (−19999 to 99999) :9999 to 99999 :9999 --- ---
