2-22
List of Settings Section 2
List of
Settings
Communications Setting Level
Note The values beginning with H' in the Monitor/Setting range column are used when setting or monitor-
ing data via communications.
Advanced Function Setting Level
Note (1) The values beginning with H' in the Monitor/Setting range column are used when setting or moni-
toring data via communications.
(2) If the event connector is provided as a standard feature or an event connector is added, use EV
for the "bank selection" setting.
Variable
type
Address Parameter
name
Charac-
ter
Monitor/Setting range Character Default
setting
Decimal point Unit
CA 0000 Communications
unit number
u-no H’00000000 to H’00000063: (0 to 99) 0 to 99 1 --- ---
0001 Baud rate bps H’00000000: 9.6 (0), H’00000001: 19.2 (1),
H’00000002: 38.4 (2)
9. 6, 19. 2. 38. 49. 6 --- kbps
0002 Communications
data length
len H’00000000: 7 (0), H’00000001: 8 (1) 7, 87--- bit
0003 Communications
stop bits
sbit H’00000000: 1 (0), H’00000001: 2 (1) 1, 22--- bit
0004 Communications
parity
prty H’00000000: None (0), H’00000001: Even (1),
H’00000002: Odd (2)
none, even, odd even --- ---
0005 Send wait time sdwt H’00000000 to H’00000063: (0 to 99) 0 to 99 20 --- ms
Variable
type
Address Parameter
name
Charac-
ter
Monitor/Setting range Character Default
setting
Decimal point Unit
CB 0002 Output OFF delay off-d H’00000000 to H’000007CF: (0 to 1999) 0 to 1999 0 --- ms
0003 Shot output shot H’00000000 to H’000007CF: (0 to 1999) 0 to 1999 0 --- ms
0004 Output logic out-n H’00000000: Close in alarm (0),
H’00000001: Open in alarm (1)
n-o, n-c n-o --- ---
0009 Bank selection bnk-c H’00000000: OFF (0), H’00000001: KEY (1),
H’00000002: EV (2)
off, key, ev off (See
note 2.)
--- ---
To Next Page
