1-7
FINS-mini Text Section 1-3
CompoWay/F
Communications
Response text FINS-mini response text consists of the MRC and SRC, followed by an MRES
(main response code) and SRES (sub response code), and then the required
data.
If the specified FINS-mini command was not successfully executed, the
response will only contain the MRC, SRC, MRES and SRES.
List of FINS-mini Service Commands (CompoWay/F Communications)
MRC SRC Service name Description
“01” “01” Monitor value/setting data read Reads monitor values/setting
data.
“01” “02” Monitor value/setting data write Writes monitor values/setting
data.
“01” “04” Monitor value/setting data com-
pound read
Performs multiple reads of moni-
tor values/setting data.
“01” “13” Monitor value/setting data com-
pound write
Performs multiple writes of mon-
itor values/setting data.
“01” “10” Monitor value/setting data com-
pound stored read
Sequentially reads contents of
addresses specified in “monitor
value/setting data compound
read store.”
“01” “11” Monitor value/setting data com-
pound read store (write)
Specifies addresses to be read
using “monitor value/setting data
compound stored read.”
“01” “12” Monitor value/setting data com-
pound read store check (read)
Reads the contents stored using
“variable area compound read
store.”
“05” “03” Machine attribute read Reads the model and other
attributes.
“06” “01” Controller status read Reads the operation status.
“08” “01” Echo-back test Performs an echo-back test.
“30” “05” Operation command Commands such as Run/Stop,
AT Execute/Cancel, and “Move
to setting area 1".
02H "00" 03H
FINS-mini
Response textEnd code
STX
SRES
2 bytes
Data
ETX BCC
MRC
2
SRC
2
MRES
2
Node
No.
Sub-
address
