1-10
Writing to the Variable Area Section 1-6
CompoWay/F
Communications
1-6 Writing to the Variable Area
Write to the data area by setting the required data in the following FINS-mini
command text format.
Command FINS-mini Command Text
Response FINS-mini Response Text
Response Codes
Data name Explanation
MRC/SRC Specifies the FINS-mini monitor value/setting data write
command.
Variable type Specify a variable type.
First address of write Specify the address for the beginning of the write.
Bit position Not used on the K3HB. Specify “00”.
Number of elements Specifies the number of variables to be written (max. of
24 (H'18)). Not needed for a compound write.
Write data Enter data to be written.
"01" "02" "00"
Write data
Number of
elements
Variable
type
SRCMRC
"0001" to "0018"
24222
Starting
address
of write
Bit
position
4
Data name Explanation
MRC/SRC FINS-mini command text appears here.
Response code Result of execution of the command.
Response
code
Error name Explanation
“1002” Command length too
short
The command is too short.
“1101” Area type error Incorrect variable type.
“1003” Number of elements/Data
number do not agree
The specified number of elements does not
agree with the actual number of data ele-
ments.
“1100” Parameter error Bit position specification other than “00”.
Written data was outside of setting range.
“2203” Operation error Write via communications is disabled.
Write to setting area 1 was attempted from
setting area 0.
Write to setting data of protect level was
attempted from other than protect level.
Calibration level in progress.
Unit error, unit change, display unit error,
internal non-volatile memory error.
“0000” Normal end
"01" "02"
Response code
(MRES/SRES)
SRCMRC
22 4
