2 Installing the NB Unit and Connecting Peripheral Devices
2-8
NB-series Programmable Terminals Setup Manual(V107)
2-3 Connecting of NB-series with PC
In order to transmit the screen data established by the NB-Designer to the NB Unit, the NB Unit needs
to be connected to a PC with a RS-232C, USB or Ethernet cable.
Take NB5Q/NB7W-TW01B as example:
Connect the RS-232C cable at the PC side to the serial port COM1 of the NB Unit.
Communication conditions
Select the downloader mode through the tool menu of the NB-Designer. For details, refer to 3-15
Download in the NB-Designer Operation Manual.
Communication cable
Users can make connection cables by themselves. For details, refer to A-4 Fabrication of the
Connection Cable in the NB Series Setup Manual.
2-3-1 Connecting by RS-232C
