Appendices
A-2
NB-series Programmable Terminals Setup Manual(V107)
A-1 Specifications
Display specifications
A-1-1 General Specifications
Items Specifications
Model
NB3Q NB5Q NB7W NB10W
TW00B TW01B TW00B TW01B TW00B TW01B TW01B
Rated power supply voltage DC24V±15%(DC20.4~27.6V)
Power consumption 5W 9W 6W 10W 7W 11W 14W
Ambient operating
temperature
0°C~50°C
Ambient storage temperature
-20°C~60°C
Ambient operating humidity 10%~90% RH (without condensation)
Ambient storage humidity 10%~90% RH (without condensation)
Operating environment No corrosive gases
Noise Immunity Compliant with IEC61000-4-4, 2KV (Power cable)
Vibration resistance
(During operation)
10 to 57Hz with a 0.075mm amplitude, 57 to 150Hz 9.8m/s
2
for 30 min each in X, Y and Z directions
Shock resistance
(During operation)
147m/s
2
for 3 times each in X, Y and Z directions, with each time lasting for 11 ms
Dimensions W×H×D(mm) 129.8×103.8×52.8 184.0×142.0×46.0 202.0×148.0×46.0
268.8×210.8×54.0
Panel opening dimension
W×H(mm)
119.0×93.0 172.4×131.0 191.0×137.0
258.0×200.0
Panel thickness range 1.6~4.8 mm
Weight 310g 315g 620g 625g 710g 715g 1545g
Degree of protection Front operation part: IP65
(Dust proof and drip proof only from the front of the panel)
Battery life 5 years (at 25 °C)
Applicable standards EC Directives, KC, cULus508
A-1-2 Performance Specifications
Items
Specifications
NB3Q NB5Q NB7W NB10W
TW00B TW01B TW00B TW01B TW00B TW01B TW01B
Display
panel
Display device 3.5"TFT LCD 5.6"TFT LCD 7"TFT LCD
10.1"TFT LCD
Resolution 320×240 320×234 800×480
800×480
Display color 65536 colors
Valid display area
W×H(mm)
71×53 113×85 154×85
221×133
Backlight Life 50,000 hours (Typ) of operating time at the normal temperature (25 °C) with
40% brightness
Front-side LED ON: power connected
OFF: power disconnected
