Oper at o r Pan el V O L UM E T R I C D O SER M AC H I NE – M o d. DV G 5 00R P – OM R O N N B 5 Q 11/24
Explanation of the main alarms which can be displayed on the Machine:
 General Emergency
It is visualized when the emergency is pressed or the machine is
switched off and you don’t reset the machine by the blue button on the
pushbutton.
Important: Before executing the machine reset please be sure that the emergency is
reactivated by pulling the red button.
 Low air pressure
It is visualized when the pressure i slow or absent.
 Inverter Belt
It is visualized when the inverter of the belt goes in alarm.
 Inverter Plate Rotation 1
It is visualized when the inverter of the plate rotation 1 goes in alarm.
 Inverter Plate Rotation 2
It is visualized when the inverter of the plate rotation 2 goes in alarm.
 Servodrive Piston 1
It is visualized when the inverter of the servodrive piston 1 goes in alarm.
 Servodrive Piston 2
It is visualized when the inverter of the servodrive piston 1 goes in alarm.
SILENCE
If you press this button, you stop the acoustic alarm.
RESET
If you press this button, you reset the alarms which are no more activated.
If you press this button, you enter the Main Page Menu.
