Omron NJ Series Troubleshooting Manual

3-73
3 Error Tables
NJ-series Troubleshooting Manual (W503)
3-1 Errors by Source
3
3-1-3 Errors in the Motion Control Function Module
57290000 hex
(Ver. 1.06)
Track Option
Structure ON
Compensa-
tion Setting
Out of Range
The value of
OnCompensation
that is specified in
the TrackOptions in-
out variable to a
motion control
instruction is out of
range.
• The value of the member of the
structure variable that was
specified for the in-out variable
of the instruction is out of
range.
S NJ-series
Motion Con-
trol Instruc-
tions
Reference
Manual (Cat.
No. W508)
572A0000 hex
(Ver. 1.06)
Track Option
Structure
OFF Com-
pensation
Setting Out of
Range
The value of Off-
Compensation that
is specified in the
TrackOptions in-out
variable to a motion
control instruction is
out of range.
• The value of the member of the
structure variable that was
specified for the in-out variable
of the instruction is out of
range.
S Same as
above.
572B0000 hex
(Ver. 1.06)
Number of
Array Ele-
ments in
Switch Struc-
ture Variable
Out of Range
The number of ele-
ments in an array in
the structure vari-
able that is speci-
fied in the Switches
in-out variable to a
motion control
instruction is out of
range.
• The number of elements in an
array of the structure variable
that was specified for the in-out
variable of the instruction is out
of range.
S Same as
above.
572C0000 hex
(Ver. 1.06)
Number of
Array Ele-
ments in Out-
put Signal
Structure
Variable Out
of Range
The number of ele-
ments in an array in
the structure vari-
able that is speci-
fied in the Outputs
in-out variable to a
motion control
instruction is out of
range.
• The number of elements in an
array of the structure variable
that was specified for the in-out
variable of the instruction is out
of range.
S Same as
above.
572D0000 hex
(Ver. 1.06)
Number of
Array Ele-
ments in
Track Option
Structure
Variable Out
of Range
The number of ele-
ments in an array in
the structure vari-
ab
le that is speci-
fied in the
Tr
ackOptions in-out
variable to a motion
control instruction is
out of range.
• The number of elements in an
array of the structure variable
that was specified for the in-out
variable of the instruction is out
of range.
S Same as
above.
572E0000 hex
(Ver. 1.06)
Numbers of
Elements in
Output Sig-
nals and
Track Option
Arrays Not
Matched
The arrays in the
structure variables
that are specified
for the Outputs and
TrackOptions in-out
variables to a
motion control
instruction do not
have the same
number of ele-
ments.
• The arrays in the output signal
structure variable and track
option structure variable that
are specified for the in-out vari-
ables to the instruction do not
have the same number of ele-
ments.
S Same as
above.
57310000 hex
(Ver. 1.06)
Same Track
Number Set-
ting in Switch
Structure Out
of Range
The same track
number was speci-
fied more than the
allowable number of
times for the Tra ck-
Number in the
Switches in-out
variable to a motion
control instruction.
• The same track number was
specified more than the allow-
able number of times for the
TrackNumber in the Switches
in-out variable to a motion con-
trol instruction.
S Same as
above.
Event code Event name Meaning Assumed cause
Level
Reference
Maj Prt Min Obs Info
