3 Error Tables
3-124
NJ-series Troubleshooting Manual (W503)
48020000 hex System Error An error occurred in
the system.
• A serious error occurred in the
system in the Controller.
S FH/FZ5 Vision
System
FH/FZ5 Series
User’s Manual
for Communi-
cations Set-
tings (Z342)
58210000 hex Output Con-
trol Timeout
for Parallel
I/O, PLC
Link, or Eth-
erNet/IP
A timeout occurred
in data output hand-
shaking control for
measurement
results.
• The data output handshaking
controls in the program (i.e., the
ON/OFF timing of the DSA sig-
nal) are not correct.
• The output control timeout time
is too short in comparison with
the program processing time.
• The parallel I/O DSA or GATE
signal is not wired correctly.
S Same as
above.
58220000 hex Output Con-
trol Timeout
for EtherCAT
A timeout occurred
in data output hand-
shaking control for
measurement
results.
• The data output handshaking
controls in the program (i.e., the
ON/OFF timing of the Result
Set Request signal) are not cor-
rect.
• The output control timeout time
is too short in comparison with
the program processing time.
S Same as
above.
78190000 hex Image Log-
ging Disk
Write Error
Writing data to the
image logging disk
failed.
• A logging disk is not inserted.
• The available space on the log-
ging disk is not sufficient.
• There is no logging folder.
• Security restrictions are set on
the logging disk.
S Same as
above.
781A0000 hex Setting Data
Transfer Error
An error occurred
while transferring
the scene data.
• Scene data was edited when
there was little available space
on the RAM disk and the opera-
tion mode was Single- line
High-speed Mode.
• The data transfer button was
clicked when there was little
available space on the RAM
disk and the operation mode
was Non-stop Adjustment
Mode.
S Same as
above.
781B0000 hex Output Buf-
fer Error
(EtherCAT)
The data output
buffer for measure-
ment data is full.
• Data measurements are being
performed on a period that is
shorter than the time that is
required for data output hand-
shake controls in the program.
S Same as
above.
88080000 hex PLC Link
Communica-
tions Error
A PLC Link cannot
be
established.
• T
here is a mistake in the PLC
or Vision Sensor communica-
tions settings.
• The Ethernet or RS-232C cable
is damaged.
S Same as
above.
