Omron NJ Series Troubleshooting Manual

3 Error Tables
3-152
NJ-series Troubleshooting Manual (W503)
05110000 hex* Cold Junction Sensor Error NX-series Analog I/O Units W522
05200000 hex* System Error NX-series Safety Control Unit Z930
05210000 hex* Internal Circuit Error at Safety Input NX-series Safety Control Unit Z930
05220000 hex* Internal Circuit Error at Test Output NX-series Safety Control Unit Z930
05230000 hex* Internal Circuit Error at Safety Output NX-series Safety Control Unit Z930
08010000 hex Battery Warning Servo G5 I576
08020000 hex Fan Warning Servo G5 and G5 Linear I576, I577
08030000 hex Encoder Communications Warning Servo G5 I576
08040000 hex Encoder/Serial Conversion Unit Over-
heating Warning
Servo G5 and G5 Linear I576, I577
08050000 hex Life Expectancy Warning Servo G5 and G5 Linear I576, I577
08060000 hex External Encoder Error Warning Servo G5 and G5 Linear I576, I577
08070000 hex External Encoder Communications
Warning
Servo G5 and G5 Linear I576, I577
08080000 hex Encoder Communications Disconnec-
tion Error
Servo G5 I576
08090000 hex Encoder Communications Error Servo G5 I576
080A0000 hex Encoder Communications Data Error Servo G5 I576
080B0000 hex Safety Input Error Servo G5 and G5 Linear I576, I577
080C0000 hex External Encoder Connection Error Servo G5 and G5 Linear I576, I577
080D0000 hex External Encoder Communications
Data Error
Servo G5 and G5 Linear I576, I577
080E0000 hex External Encoder Status Error 0 Servo G5 and G5 Linear I576, I577
080F0000 hex External Encoder Status Error 1 Servo G5 and G5 Linear I576, I577
08100000 hex External Encoder Status Error 2 Servo G5 and G5 Linear I576, I577
08110000 hex External Encoder Status Error 3 Servo G5 and G5 Linear I576, I577
08120000 hex External Encoder Status Error 4 Servo G5 and G5 Linear I576, I577
08130000 hex External Encoder Status Error 5 Servo G5 and G5 Linear I576, I577
08140000 hex Phase-A Connection Error Servo G5 and G5 Linear I576, I577
08150000 hex Phase-B Connection Error Servo G5 and G5 Linear I576, I577
08160000 hex Phase-Z Connection Error Servo G5 and G5 Linear I576, I577
08170000 hex Encoder Data Restoration Error Servo G5 I576
08180000 hex External Encoder Data Restoration
Error
Servo G5 I576
08210000 hex* Fan/Power Supply Error FH/FZ5 Series Vision System Z342
08220000 hex* Camera Overcurrent Detected FH/FZ5 Series Vision System Z342
08230000 hex* Parallel I/O Overcurrent Detected FH/FZ5 Series Vision System Z342
10010000 hex Non-volatile Memory Restored or For-
matted
Errors for Self Diagnosis W500
10020000 hex Non-volatile Memory Data Corrupted Errors for Self Diagnosis W500
10030000 hex SD Memory Card Invalid Format Errors for Self Diagnosis W500
10040000 hex SD Memory Card Restored or For-
matted
Errors for Self Diagnosis W500
10060000 hex SD Memory Card Data Corrupted Errors for Self Diagnosis W500
10070000 hex SD Memory Card Access Power OFF
Error
Errors for Self Diagnosis W500
10080000 hex Main Memory Check Error Errors for Self Diagnosis W500
10090000 hex Battery-backup Memory Check Error Errors for Self Diagnosis W500
Event code Event name Functional classification Reference

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
