Omron NJ Series

3-153
3 Error Tables
NJ-series Troubleshooting Manual (W503)
3-2 Events in Order of Event Codes
3
3-2-2 Error Table
100C0000 hex* Event Level Setting Error Errors for Self Diagnosis W500
10200000 hex User Program/Controller Configura-
tions and Setup Transfer Error
Errors Related to Controller Opera-
tion
W500, W501
10210000 hex Illegal User Program Execution ID Errors Related to Controller Opera-
tion
W500, W501
10230000 hex Event Log Restoration Error Errors Related to Controller Opera-
tion
W500, W501
10240000 hex Illegal User Program Errors Related to Controller Opera-
tion
W500, W501
10250000 hex Illegal User Program/Controller Con-
figurations and Setup
Errors Related to Controller Opera-
tion
W500, W501
10260000 hex Trace Setting Transfer Failure Errors Related to Controller Opera-
tion
W500, W501
10270000 hex* Error in Starting Automatic Transfer Errors Related to Controller Opera-
tion
W500, W501
10280000 hex* Error in Executing Automatic Transfer Errors Related to Controller Opera-
tion
W500, W501
10290000 hex* Backup Failed to Start Errors Related to Controller Opera-
tion
W500, W501
102A0000 hex* Backup Failed Errors Related to Controller Opera-
tion
W500, W501
102B0000 hex* Restore Operation Failed to Start Errors Related to Controller Opera-
tion
W500, W501
102C0000 hex* Restore Operation Failed Errors Related to Controller Opera-
tion
W500, W501
102D0000 hex* CJ-series Unit Backup Failed Errors Related to Unit Configuration W500
102E0000 hex* CJ-series Unit Restore Operation
Failed
Errors Related to Unit Configuration W500
102F0000 hex* EtherCAT Slave Backup Failed Built-in EtherCAT Master in CPU Unit W505
10300000 hex* EtherCAT Slave Restore Operation
Failed
Built-in EtherCAT Master in CPU Unit W505
10310000 hex* Incorrect SD Memory Card Removal Errors for Self Diagnosis W500
10400000 hex* Analog Unit Calibration Parameter
Error
NX-series Analog I/O Units W522
10410000 hex* Control Parameter Error in Master NX-series Digital I/O Units, NX-series
Analog I/O Units, and NX-series
Position Interface Units
W521, W522,
and W524
10420000 hex* Non-volatile Memory Control Parame-
ter Error
NX-series EtherCAT Coupler Unit W519
10430000 hex* Memory Corruption Detected NX-series EtherCAT Coupler Unit W519
10500000 hex* NX Bus Communications Settings
Read Error
NX-series Safety Control Unit Z930
10510000 hex* Safety Application Data Read Error NX-series Safety Control Unit Z930
10520000 hex* NX Bus Communications Settings
and Safety Application Data Mis-
match
NX-series Safety Control Unit Z930
10530000 hex* Non-volatile Memory Access Error NX-series Safety Control Unit Z930
14010000 hex CPU Bus Unit Setup Area Error Errors Related to FINS Communica-
tions
W501
14200000 hex MAC Address Error Built-in EtherNet/IP Port on CPU Unit W506
14210000 hex Identity Error Built-in EtherNet/IP Port on CPU Unit W506
14220000 hex EtherNet/IP Processing Error Built-in EtherNet/IP Port on CPU Unit W506
Event code Event name Functional classification Reference
