3-157
3 Error Tables
NJ-series Troubleshooting Manual (W503)
3-2 Events in Order of Event Codes
3
3-2-2 Error Table
34AB0000 hex Basic Ethernet Setting Error CJ-series EtherNet/IP Units W495
34AC0000 hex IP Address Table Error CJ-series EtherNet/IP Units W495
34AD0000 hex IP Router Table Error CJ-series EtherNet/IP Units W495
34AE0000 hex Routing Table Error CJ-series EtherNet/IP Units W495
34AF0000 hex Ethernet Advanced Setting Error CJ-series EtherNet/IP Units W495
34B00000 hex Address Mismatch CJ-series EtherNet/IP Units W495
34BC0000 hex Routing Table Error CJ-series DeviceNet Units W497
34BD0000 hex Verification Error CJ-series DeviceNet Units W497
34BE0000 hex Structure Error CJ-series DeviceNet Units W497
34BF0000 hex Master I/O Refresh Error CJ-series DeviceNet Units W497
34C00000 hex Master User-set Allocations User Set-
ting Failed
CJ-series DeviceNet Units W497
34C10000 hex Communications Cycle Time Setting
Failed
CJ-series DeviceNet Units W497
34C20000 hex Slave I/O Refresh Error CJ-series DeviceNet Units W497
34C30000 hex Slave User Allocation Area Setting
Failed
CJ-series DeviceNet Units W497
34E00000 hex Data Setting Warning Servo G5 and G5 Linear I576, I577
34E10000 hex Servo Drive Overheat Servo G5 and G5 Linear I576, I577
34E20000 hex Overload Servo G5 and G5 Linear I576, I577
34E30000 hex Regeneration Overload Servo G5 and G5 Linear I576, I577
34E40000 hex Error Counter Overflow Servo G5 and G5 Linear I576, I577
34E50000 hex Excessive Velocity Error Servo G5 and G5 Linear I576, I577
34E60000 hex Overspeed Servo G5 and G5 Linear I576, I577
34F00000 hex PDO Setting Error MX2/RX-series Inverters with Ether-
CAT Communications Units
I574
34F80000 hex Dummy Sensors Setting Error E3X-series Fiber Sensors with Ether-
CAT Communications Unit for Digital
Sensors and EtherCAT Digital Sen-
sor Communications Units Operation
Manual
E413 and
E429
35000000 hex* Unit Configuration Information Error NX-series EtherCAT Coupler Unit W519
35010000hex* Unit Configuration Verification Error NX-series EtherCAT Coupler Unit W519
35020000hex* NX Unit Minor Fault NX-series EtherCAT Coupler Unit W519
35030000hex* NX Unit Observation NX-series EtherCAT Coupler Unit W519
35040000hex* Mailbox Setting Error NX-series EtherCAT Coupler Unit W519
35050000hex* RxPDO Setting Error NX-series EtherCAT Coupler Unit W519
35060000hex* TxPDO Setting Error NX-series EtherCAT Coupler Unit W519
35070000 hex* PDO WDT Setting Error NX-series EtherCAT Coupler Unit W519
35080000 hex* SM Event Mode Setting Error NX-series EtherCAT Coupler Unit W519
35090000 hex* TxPDO Mapping Error NX-series EtherCAT Coupler Unit W519
Event code Event name Functional classification Reference
