3 Error Tables
3-162
NJ-series Troubleshooting Manual (W503)
54013012 hex* DB Connection Instruction Execution
Timeout
DB Connection Instructions W527
54013013 hex* DB Connection Service Error Stop DB Connection Instructions W527
54013014 hex* Data Already Spooled DB Connection Instructions W527
54013015 hex* DB Connection Service Initializing DB Connection Instructions W527
54013016 hex* DB in Process DB Connection Instructions W527
54013017 hex* Operation Log Disabled DB Connection Instructions W527
54013461 hex Process Data Object Setting Missing Instructions W502
54015420 hex Electronic Gear Ratio Numerator Set-
ting Out of Range
Instructions W502
54015421 hex Electronic Gear Ratio Denominator
Setting Out of Range
Instructions W502
54015422 hex Target Velocity Setting Out of Range Instructions W502
54015423 hex Acceleration Setting Out of Range Instructions W502
54015424 hex Deceleration Setting Out of Range Instructions W502
54015425 hex Jerk Setting Out of Range Instructions W502
54015427 hex Torque Ramp Setting Out of Range Instructions W502
54015428 hex Master Coefficient Scaling Out of
Range
Instructions W502
54015429 hex Slave Coefficient Scaling Out of
Range
Instructions W502
5401542A hex Feeding Velocity Setting Out of
Range
Instructions W502
5401542B hex Buffer Mode Selection Out of Range Instructions W502
5401542C hex Coordinate System Selection Out of
Range
Instructions W502
5401542D hex Circular Interpolation Mode Selection
Out of Range
Instructions W502
5401542E hex Direction Selection Out of Range Instructions W502
5401542F hex Path Selection Out of Range Instructions W502
54015430 hex Position Type Selection Out of Range Instructions W502
54015431 hex Travel Mode Selection Out of Range Instructions W502
54015432 hex Transition Mode Selection Out of
Range
Instructions W502
54015433 hex Continue Method Selection Out of
Range
Instructions W502
54015434 hex Combine Mode Selection Out of
Range
Instructions W502
54015435 hex Synchronization Start Condition
Selection Out of Range
Instructions W502
54015436 hex Master and Slave Defined as Same
Axis
Instructions W502
54015437 hex Master and Auxiliary Defined as
Same Axis
Instructions W502
54015438 hex Master/Slave Axis Numbers Not in
Ascending Order
Instructions W502
54015439 hex Incorrect Cam Table Specification Instructions W502
5401543A hex Synchronization Stopped Instructions W502
5401543B hex Motion Control Instruction Re-execu-
tion Disabled
Instructions W502
Event code Event name Functional classification Reference
