Omron NJ Series Troubleshooting Manual

3 Error Tables
3-176
NJ-series Troubleshooting Manual (W503)
742D0000 hex No Home Proximity Input General Motion Control W507
742F0000 hex Slave Error Detected General Motion Control W507
74300000 hex Axes Group Composition Axis Error General Motion Control W507
74320000 hex Slave Observation Detected General Motion Control W507
74330000 hex MC Common Error Occurrence General Motion Control W507
74340000 hex Latch Position Overflow General Motion Control W507
74350000 hex Latch Position Underflow General Motion Control W507
74360000 hex Master Sync Direction Error General Motion Control W507
74370000 hex Slave Disconnection during Servo ON General Motion Control W507
74380000 hex Feed Distance Overflow General Motion Control W507
74390000 hex Error in Changing Servo Drive Con-
trol Mode
General Motion Control W507
743A0000 hex Master Axis Position Read Error General Motion Control W507
743B0000 hex Auxiliary Axis Position Read Error General Motion Control W507
743C0000 hex Cannot Execute Save Cam Table
Instruction
General Motion Control W507
743D0000 hex* Incorrect Synchronization Command NX-series Position Interface Units W524
743E0000 hex* Illegal Following Error NX-series Position Interface Units W524
743F0000 hex* Illegal State Transition NX-series Position Interface Units W524
74600000 hex Master Function Enable/Disable
Failed
CJ-series DeviceNet Units W497
74610000 hex Master Fixed Allocation Area Setting
Failed
CJ-series DeviceNet Units W497
74620000 hex Scan List Register/Clear Failed CJ-series DeviceNet Units W497
74630000 hex Slave Function Enable/Disable Failed CJ-series DeviceNet Units W497
74640000 hex Slave Fixed Allocation Area Setting
Failed
CJ-series DeviceNet Units W497
74800000 hex Command Warning Servo G5 and G5 Linear I576, I577
74810000 hex Command Error Servo G5 and G5 Linear I576, I577
74900000 hex* Multiple Control Signal Input Error ZW-CE1@T Confocal Fiber Type Dis-
placement Sensor
Z332
74910000 hex* EXE Input Error ZW-CE1@T Confocal Fiber Type Dis-
placement Sensor
Z332
74920000 hex* SYNC Input Error ZW-CE1@T Confocal Fiber Type Dis-
placement Sensor
Z332
74930000 hex* TIMING Input Error ZW-CE1@T Confocal Fiber Type Dis-
placement Sensor
Z332
74940000 hex* RESET Input Error ZW-CE1@T Confocal Fiber Type Dis-
placement Sensor
Z332
74950000 hex* ZERO Input Error ZW-CE1@T Confocal Fiber Type Dis-
placement Sensor
Z332
74960000 hex* ZEROCLR Input Error ZW-CE1@T Confocal Fiber Type Dis-
placement Sensor
Z332
74A00000 hex* SF_Antivalent Error NX-series Safety Control Unit Z930
74A10000 hex* SF_EDM Error NX-series Safety Control Unit Z930
74A20000 hex* SF_EmergencyStop Error NX-series Safety Control Unit Z930
Event code Event name Functional classification Reference

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
