Omron NJ Series Troubleshooting Manual

3-177
3 Error Tables
NJ-series Troubleshooting Manual (W503)
3-2 Events in Order of Event Codes
3
3-2-2 Error Table
74A30000 hex* SF_EnableSwitch Error NX-series Safety Control Unit Z930
74A40000 hex* SF_Equivalent Error NX-series Safety Control Unit Z930
74A50000 hex* SF_ESPE Error NX-series Safety Control Unit Z930
74A60000 hex* SF_GuardLocking Error NX-series Safety Control Unit Z930
74A70000 hex* SF_GuardMonitoring Error NX-series Safety Control Unit Z930
74A80000 hex* SF_ModeSelector Error NX-series Safety Control Unit Z930
74A90000 hex* SF_MutingPar Error NX-series Safety Control Unit Z930
74AA0000 hex* SF_MutingPar_2Sensor Error NX-series Safety Control Unit Z930
74AB0000 hex* SF_MutingSeq Error NX-series Safety Control Unit Z930
74AC0000 hex* SF_OutControl Error NX-series Safety Control Unit Z930
74AD0000 hex* SF_SafetyRequest Error NX-series Safety Control Unit Z930
74AE0000 hex* SF_TestableSafetySensor Error NX-series Safety Control Unit Z930
74AF0000 hex* SF_TwoHandControlTypeII Error NX-series Safety Control Unit Z930
74B00000 hex* SF_TwoHandControlTypeIII Error NX-series Safety Control Unit Z930
78010000 hex Operation Command Competition Servo G5 and G5 Linear I576, I577
78020000 hex Absolute Encoder Status Error Servo G5 I576
78080000 hex TRIG Input Error EtherCAT FQ-M-series Specialized
Vision Sensors for Positioning
Z314
780A0000 hex Scene Data Error EtherCAT FQ-M-series Specialized
Vision Sensors for Positioning
Z314
780B0000 hex Model Error EtherCAT FQ-M-series Specialized
Vision Sensors for Positioning
Z314
780C0000 hex Logging Error EtherCAT FQ-M-series Specialized
Vision Sensors for Positioning
Z314
780D0000 hex Output Timeout EtherCAT FQ-M-series Specialized
Vision Sensors for Positioning
Z314
780E0000 hex Output Size Error EtherCAT FQ-M-series Specialized
Vision Sensors for Positioning
Z314
78190000 hex* Image Logging Disk Write Error FH/FZ5 Series Vision System Z342
781A0000 hex* Setting Data Transfer Error FH/FZ5 Series Vision System Z342
781B0000 hex* Output Buffer Error (EtherCAT) FH/FZ5 Series Vision System Z342
80010000 hex Illegal Packet Discarded Errors Related to Unit Configuration W500
80100000 hex Packet Discarded Errors Related to FINS Communica-
tions
W501
80110000 hex Packet Discarded Errors Related to FINS Communica-
tions
W501
80120000 hex Packet Discarded Errors Related to FINS Communica-
tions
W501
80200000 hex* NX Unit I/O Communications Error NX-series Digital I/O Units, NX-series
Analog I/O Units, NX-series Position
Interface Units, and NX-series Safety
Control Unit
W521, W522,
W524, and
Z930
Event code Event name Functional classification Reference

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
