Omron NJ Series Troubleshooting Manual

3 Error Tables
3-178
NJ-series Troubleshooting Manual (W503)
80210000 hex* NX Unit Output Synchronization Error NX-series Digital I/O Units, NX-series
Analog I/O Units, and NX-series
Position Interface Units
W521, W522,
and W524
80220000 hex* NX Message Communications Error NX-series EtherCAT Coupler Unit,
NX-series Analog I/O Units, NX-
series Position Interface Units, and
NX-series Safety Control Unit
W519, W522,
W524, and
Z930
80230000 hex* NX Message Communications Error Errors Related to Controller Opera-
tion
W500, W501
80240000 hex* NX Unit Clock Not Synchronized
Error
NX-series Digital I/O Units, NX-series
Analog I/O Units, and NX-series
Position Interface Units
W521, W522,
and W524
80300000 hex* Safety Process Data Communica-
tions Timeout
NX-series Safety Control Unit Z930
84010000 hex IP Address Duplication Error Built-in EtherNet/IP Port on CPU Unit W506
84020000 hex BOOTP Server Connection Error Built-in EtherNet/IP Port on CPU Unit W506
84030000 hex DNS Server Connection Error Built-in EtherNet/IP Port on CPU Unit W506
84040000 hex NTP Server Connection Error Built-in EtherNet/IP Port on CPU Unit W506
84050000 hex Packet Discarded Due to Full Recep-
tion Buffer
Built-in EtherNet/IP Port on CPU Unit W506
84060000 hex Link OFF Detected Built-in EtherNet/IP Port on CPU Unit W506
84070000 hex Tag Data Link Connection Failed Built-in EtherNet/IP Port on CPU Unit W506
84080000 hex Tag Data Link Timeout Built-in EtherNet/IP Port on CPU Unit W506
84090000 hex* Tag Data Link Connection Timeout Built-in EtherNet/IP Port on CPU Unit W506
84200000 hex Link OFF Error Built-in EtherCAT Master in CPU Unit W505
84210000 hex Network Configuration Error Built-in EtherCAT Master in CPU Unit W505
84220000 hex Network Configuration Verification
Error
Built-in EtherCAT Master in CPU Unit W505
84230000 hex Slave Initialization Error Built-in EtherCAT Master in CPU Unit W505
84280000 hex Slave Application Error Built-in EtherCAT Master in CPU Unit W505
84290000 hex Process Data Transmission Error Built-in EtherCAT Master in CPU Unit W505
842B0000 hex Process Data Reception Timeout Built-in EtherCAT Master in CPU Unit W505
842C0000 hex Process Data Communications Error Built-in EtherCAT Master in CPU Unit W505
842D0000 hex EtherCAT Message Error Built-in EtherCAT Master in CPU Unit W505
84400000 hex EtherCAT Slave Communications
Error
General Motion Control W507
84600000 hex Communications Error CJ-series CompoNet Master Unit W493
84610000 hex Repeater Unit Communications Error CJ-series CompoNet Master Unit W493
84680000 hex Transmission Error CJ-series Serial Communications
Units
W494
84690000 hex Overrun Error CJ-series Serial Communications
Units
W494
846A0000 hex Framing Error CJ-series Serial Communications
Units
W494
846B0000 hex Parity Error CJ-series Serial Communications
Units
W494
846C0000 hex Overrun Error, Framing Error, or Par-
ity Error (Transmission Error)
CJ-series Serial Communications
Units
W494
846D0000 hex Transmission Error (CRC Error) CJ-series Serial Communications
Units
W494
Event code Event name Functional classification Reference

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
