Omron NJ Series Troubleshooting Manual

3 Error Tables
3-8
NJ-series Troubleshooting Manual (W503)
Errors Related to Controller Operation
Event code Event name Meaning Assumed cause
Level
Reference
Maj Prt Min Obs Info
10200000 hex User Pro-
gram/Con-
troller
Configura-
tions and
Setup Trans-
fer Error
The user program
or Controller Con-
figurations and
Setup were not
transferred cor-
rectly.
• The user program or Controller
Configurations and Setup are
not correct because the power
supply to the Controller was
interrupted during a download
of the user program or the Con-
troller Configurations and
Setup.
• The user program or Controller
Configurations and Setup are
not correct because the power
supply to the Controller was
interrupted during online edit-
ing.
• The user program or Controller
Configurations and Setup are
not correct because the power
supply to the Controller was
interrupted during a Clear All
Memory operation.
• The user program or Controller
Configurations and Setup are
not correct because the power
supply to the Controller was
interrupted during a restore
operation.
• Non-volatile memory failed.
S NJ-series
CPU Unit
Hardware
User’s Manual
(Cat. No.
W500)
NJ-series
CPU Unit Soft-
ware User’s
Manual (Cat.
No. W501)
10210000 hex Illegal User
Program
Execution ID
The user program
execution IDs set in
the user program
and in the CPU Unit
do not match.
• The user program execution
IDs set in the user program and
in the CPU Unit do not match.
• A user program execution ID is
set in the CPU Unit but not in
the user program.
S Same as
above.
10240000 hex Illegal User
Program
The user program
is not correct.
• There are more than 8 nesting
levels for functions or function
blocks.
S Same as
above.
10250000 hex Illegal User
Pro-
gram/Con-
troller
Configura-
tions and
Setup
The upper limit of
the usable memory
was exceeded or
the user program or
Controller Configu-
rations and Setup is
corrupted.
• The upper limit of the data size
was exceeded.
• The main memory capacity was
exceeded.
• Non-volatile memory is deterio-
rating or has failed.
S Same as
above.

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
