Omron NJ Series Troubleshooting Manual

3 Error Tables
3-22
NJ-series Troubleshooting Manual (W503)
54011C04 hex CIP Timeout A CIP timeout occurred
during execution of a CIP
communications instruc-
tion.
• A device does not
exist for the specified
IP address.
• The CIP connection
for the specified han-
dle timed out and was
closed.
• Power to the remote
device is OFF.
• Communications are
stopped at the remote
device.
• The Ethernet cable
connector for Ether-
Net/IP is discon-
nected.
• The Ethernet cable for
EtherNet/IP is discon-
nected.
• Noise
S NJ-series
Instruc-
tions Ref-
erence
Manual
(Cat. No.
W502)
54011C05 hex
(Ver. 1.06)
Class-3 Connec-
tion Not Estab-
lished
Establishing a class-3 con-
nection failed for a CIP
communications instruc-
tion.
• The CIPOpen instruc-
tion was executed for
a device that does not
support class 3
(Large_Forward_Ope
n).
• The CIPOpenWithDa-
taSize instruction was
executed with a speci-
fied data size of 510
bytes or larger for a
device that does not
support class 3
(Large_Forward_Ope
n).
S Same as
above.
54011C06 hex
(Ver. 1.06)
CIP Communica-
tions Data Size
Exceeded
An attempt was made to
send a class-3 explicit mes-
sage with a data size that is
larger than the sendable
size with a CIP communica-
tions instruction.
• The data size that was
specified for the input
variable to the
CIPRead, CIPWrite, or
CIPSend instruction
exceeded the data
size that was specified
with the CIPOpen-
WithData-Size instruc-
tion.
S Same as
above.
54012000 hex Local IP Address
Setting Error
An instruction was exe-
cuted when there was a
setting error in the local IP
address.
• An instruction was
executed when there
was a setting error in
the local IP address.
S Same as
above.
54012001 hex TCP/UDP Port
Already in Use
The UDP or TCP port was
already in use when the
instruction was executed.
•
The UDP or TCP port
is already in use
.
S Same as
abo
ve.
54012002 hex Address Resolu-
tion Failed
Address resolution failed
for a remote node with the
domain name that was
specified in the instruction.
• The domain name
specified for the
instruction is not cor-
rect.
• The hosts and DNS
settings in the Control-
ler are incorrect.
• The DNS server set-
tings are incorrect.
S Same as
above.
Event code Event name Meaning Assumed cause
Level
Refer-
ence
Maj Prt Min Obs Info

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
