Omron NJ Series

3-27
3 Error Tables
NJ-series Troubleshooting Manual (W503)
3-1 Errors by Source
3
3-1-2 Errors in the PLC Function Module
54015422 hex Target Velocity
Setting Out of
Range
The parameter specified for
the Velocity input variable
to a motion control instruc-
tion is out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S NJ-series
Instruc-
tions Ref-
erence
Manual
(Cat. No.
W502)
54015423 hex Acceleration Set-
ting Out of Range
The parameter specified for
the Acceleration input vari-
able to a motion control
instruction is out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
54015424 hex Deceleration Set-
ting Out of Range
The parameter specified for
the Deceleration input vari-
able to a motion control
instruction is out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
54015425 hex Jerk Setting Out of
Range
The parameter specified for
the Jerk input variable to a
motion control instruction is
out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
54015427 hex Torque Ramp Set-
ting Out of Range
The parameter specified for
the TorqueRamp input vari-
able to a motion control
instruction is out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
54015428 hex Master Coefficient
Scaling Out of
Range
The parameter specified for
the MasterScaling input
variable to a motion control
instruction is out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
54015429 hex Slave Coefficient
Scaling Out of
Range
The parameter specified for
the SlaveScaling input vari-
able to a motion control
instruction is out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
5401
542A hex F
eeding Velocity
Setting Out of
Range
The parameter specified for
the FeedVelocity input vari-
able to a motion control
instruction is out of range.
• The Feed Velocity
(input variable Feed-
Velocity) is still at the
default (0).
S Same as
above.
5401542B hex Buffer Mode Selec-
tion Out of Range
The parameter specified for
the BufferMode input vari-
able to a motion control
instruction is out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
5401542C hex Coordinate System
Selection Out of
Range
The parameter specified for
the CoordSystem input
variable to a motion control
instruction is out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
5401542D hex Circular Interpola-
tion Mode Selec-
tion Out of Range
The parameter specified for
the CircMode input variable
to a motion control instruc-
tion is out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
5401542E hex Direction Selec-
tion Out of Range
The parameter specified for
the Direction input variable
to a motion control instruc-
tion is out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
5401542F hex Path Selection Out
of Range
The parameter specified for
the PathChoice input vari-
able to a motion control
instruction is out of range.
• Instruction input
parameter exceeded
the valid range of the
input variable.
S Same as
above.
54015430 hex Position Type
Selection Out of
Range
The parameter specified for
the ReferenceType input
variable to a motion control
instruction is out of range.
• Instruction input
parameter exceeded
the valid range of the
input v
ariab
le.
S Same as
above.
Event code Event name Meaning Assumed cause
Level
Refer-
ence
Maj Prt Min Obs Info
