RS-422 Interface Unit System Configuration
Connect a single host computer to a maximum of 16 PTs whentheRS-422Inter-
face Unit is used.
PT
PT
B500-AL004
Link Adaptor
RS-422 cable
B500-AL001
Link Adaptor
RS-422
Interface Unit
B500-AL001
Link Adaptor
RS-422
Interface Unit
IBM PC/AT or
compatible
RS-232C cable
NT-series
Support Tool
Host computer: Personal computer or FA computer
 
Section 1-3

Related product manuals
