6 Incremental Encoder Input Units
6 - 30
NX-series Position Interface Units User’s Manual (W524)
When you use an NJ/NX-series Controller with the MC Function Module, you must set the Unit as an
encoder axis. Set the axis parameter settings and assign an axis variable from the Sysmac Studio.
Refer to the NJ/NX-series CPU Unit Motion Control User’s Manual (Cat. No. W507) for detailed setting
procedures.
Observe the following precautions when you use an Incremental Encoder Input Unit with the MC Func-
tion Module.
• Connect the Incremental Encoder Input Unit after an EtherCAT Coupler Unit.
• The Unit is treated as an axis (encoder axis) from the user program, so you cannot handle the I/O
data from the Incremental Encoder Input Unit directly. Use motion control instructions and an axis
variable to manipulate this data.
• For an NX-series CPU Unit, you can execute motion control in the primary periodic task and priority-5
periodic task.
• Some functions are fixed and no selections are available. For example, gate control requires that you
always enable the counter. Counter reset and preset operations are calculated in the MC Function
Module and therefore do not change any data in the Incremental Encoder Input Unit.
Yes: Can be used, Partial: Can be used with restrictions, No: Cannot be used
You can control latching for an encoder axis with the following motion control instructions.
Using an NJ/NX-series Controller with the MC Function Module
Function
EtherCAT Coupler Unit
Free-Run refreshing
*1
*1. If you use the Unit as an axis in the MC Function Module, either synchronous I/O refreshing or task period pri-
oritized refreshing is used as the I/O refreshing method.
Synchronous I/O
refreshing
Task period prioritized
refreshing
*2
*2. Unit version 1.2 or later and an NX-ECC203 EtherCAT Coupler Unit are required.
Counter type setting No
Partial
*3
*3. Select a ring counter if you use the Incremental Encoder Input Unit as an axis in the MC Function Module.
Partial
*3
Pulse input method setting No Yes Yes
Encoder count direction No Yes Yes
Gate control No
No
*4
*4. The gate requires that you always enable the counter. The counter is enabled by default for an Incremental
Encoder Input Unit, so you do not need to change this setting.
No
*4
Counter reset No
No
*5
*5. This is performed in the MC Function Module data. It will not function in the Unit.
No
*5
Counter preset No
No
*5
No
*5
Latching No
Partial
*6
*6. You can use latching for external inputs and phase-Z inputs only. You cannot perform latching with an encoder
counter operation command.
Partial
*6
External input function selec-
tion
No
Partial
*7
*7. When you use the Unit as an axis in the MC Function Module, select either a general input or latch input for
the external input. Select a latch input to use latching. Otherwise, select a general input.
Partial
*7
Pulse rate measurement No No No
Pulse period measurement No No No
I/O refreshing method setting No
Partial
*1
Partial
*1
Time stamping
*8
*8. An EtherCAT Coupler Unit with unit version 1.1 or later is required.
No Yes Yes
