8-1 Interpreting Model Numbers
8
8-1 Interpreting Model Numbers
The model number of the Pulse Output Unit tells you the Unit type, number of axes, I/O specifications,
and other information.
NX-PG0
1
2
2
NX Series
Unit Type
Number of Channels
Pulse Output Specification and I/O Polarity
Additional Functions
2: Supports synchronous refreshing
1: Open collector output, NPN
2: Open collector output, PNP
1: 1 channel
PG0: Pulse Output Unit
