Omron NX-EC0122 User Manual

10 Troubleshooting
10 - 14
NX-series Position Interface Units User’s Manual (W524)
Event name SSI Data Setting Error Event code 3511 0000 hex
Meaning There is an error in the SSI data settings.
Source
Depends on where the Sysmac
Studio is connected and the sys-
tem configuration.
Source details
NX Unit
Detection
timing
When power is
turned ON to
the NX Unit
Error
attributes
Level
Minor fault
Recovery
Restart the NX
Unit.
Log category
System
Effects User program
Continues.
Operation
The present value data changes to 0.
The following bit changes to FALSE: Ch SSI Com-
munications Enabled bit in the SSI Status.
Sys-
tem-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
The sum of the values set for the
Valid Data Length and the Leading
Bits parameters exceeds 32.
Check that there are no mistakes
in the SSI data settings and cor-
rect any that are found.
Set the SSI data correctly.
The sum of the values set for the
Multi-turn Data Length, Single-turn
Data Length, and the Status Data
Length parameters exceeds 32.
The sum of the value set for the
start bit position and the data
length of the SSI data exceeds the
value set for the Valid Data Length
parameter.
The value set for the Encoder
Resolution parameter exceeds the
range expressed by the data
length set for the Single-turn Data
Length parameter.
Check that there are no mistakes
in the resolution settings and cor-
rect any that are found.
Set the resolution correctly.
Attached
information
Attached information 1: Error channel
1: Channel 1
2: Channel 2
Precautions/
Remarks
None
