3 Part Names and Functions
3 - 6
NX-series Position Interface Units User’s Manual (W524)
To differentiate between the two models of Terminal Blocks, use the terminal number column indica-
tions. The Terminal Block with white letters on a dark background is the NX-TB2.
Additional Information
• Each Position Interface Unit is compatible with only one of these three types of terminal
blocks. You cannot use a terminal block that does not match the specifications for a particular
Unit.
• The 12-mm-wide terminal block does not have terminal holes and release holes for terminal
numbers A7, A8, B7, and B8.
• The 24-mm-wide terminal block does not have terminal holes and release holes for terminal
numbers A7, A8, B7, B8, C7, C8, D7, and D8.
The following table gives the Terminal Blocks that are applicable to each Unit.
Letter Name Function
(A) Terminal num-
ber indication
The terminal number is identified by a column (A through D) and a row (1 through 8).
Therefore, terminal numbers are written as a combination of columns and rows, A1
through A8 and B1 through B8.
For a 24-mm-wide terminal block, the left side contains terminals A1 through A8 and
B1 through B8. The right side contains terminals C1 through C8 and D1 through D8.
The terminal number indication is the same regardless of the number of terminals on
the terminal block, as shown above.
(B) Release hole A flat-blade screwdriver is inserted here to attach and remove the wiring.
(C) Terminal hole The wires are inserted into these holes.
Applicable Terminal Blocks for Each Unit Model
Unit model
number
Terminal Block
Terminal Block model num-
ber
No. of terminals
Ground terminal
mark
Terminal current
capacity
NX-EC0112 NX-TBA161 16 None 4 A
NX-TBA162 10 A
NX-EC0122 NX-TBA161 4 A
NX-TBA162 10 A
NX-EC0132 NX-TBA121 and NX-TBB121 12 4 A
NX-TBA122 and NX-TBB122 10 A
NX-EC0142 NX-TBA121 and NX-TBB121 4 A
NX-TBA122 and NX-TBB122 10 A
NX-EC0212 NX-TBA121 4 A
NX-TBA122 10 A
NX-EC0222 NX-TBA121 4 A
NX-TBA122 10 A
NX-ECS112 NX-TBA121 4 A
NX-TBA122 10 A
NX-ECS212 NX-TBA121 4 A
NX-TBA122 10 A
NX-PG0112 NX-TBA161 16 4 A
NX-TBA162 10 A
NX-PG0122 NX-TBA161 4 A
NX-TBA162 10 A
