NX-CSG/SL5/SI/SO
4
Automation Software Sysmac Studio
Please purchase a DVD and required number of licenses the first time you purchase the Sysmac Studio. DVDs and licenses are available
individually. Each model of licenses does not include any DVD.
Note: For details of the Automation Software Sysmac Studio, refer to your local OMRON website.
*1. The Safety Edition can be used with the Communication Control Unit and EtherNet/IP Coupler Unit.
*2. The Sysmac Studio Standard Edition License (SYSMAC-SE2
L) includes functions that the Safety Edition (SYSMAC-FE001L) provides.
The Communication Control Unit can be used with the Sysmac Studio version 1.24 or higher.
Optional Products
Accessories
Communication Control Unit Accessories
End Cover (NX-END02): 1
One End Cover is provided with the Communication Control Unit.
Product name Specifications Model
Number of
licenses
Media
Sysmac Studio
Safety Edition
Ver. 1. *1
Sysmac Studio Safety Edition is a license including necessary setting functions for
the safety control system.
* This product is a license only. You need the Sysmac Studio Standard Edition
DVD media to install it.
1 license --- SYSMAC-FE001L
Sysmac Studio
Standard Edition
Ver. 1. *2
The Sysmac Studio is the software that provides an integrated environment for
setting, programming, debugging and maintenance of machine automation
controllers including the NJ/NX-series CPU Units, NY-series Industrial PC,
EtherCAT Slave, and the HMI.
Sysmac Studio runs on the following OS.
Windows 7(32-bit/64-bit version)/8(32-bit/64-bit version)/8.1(32-bit/64-bit
version)/10(32-bit/64-bit version)
---
(Media only)
DVD SYSMAC-SE200D
Product name Specification Model
Memory Card
SD memory card, 2 GB HMC-SD291
SD memory card, 4 GB HMC-SD491
Product Name Specification Model
Unit/Terminal Block Coding Pins For 10 Units (Terminal Block: 30 pins, Unit: 30 pins) NX-AUX02
Product name
Specification
Model
No. of terminals
Terminal number
indications
Ground terminal
mark
Terminal current
capacity
Terminal Block
8 A/B Provided 10 A NX-TBC082
8 A/B None 10 A NX-TBA082
16 A/B None 10 A NX-TBA162
