Machine Automation Controller NX1

Unit Power Supply System

Add one or more NX-PF Additional I/O Power Supply Units when I/O power is supplied from the NX bus to NX Units connected to the CPU Unit.

Check the table below.

Note: Refer to the NX-series NX102 CPU Unit Hardware User’s

Manual (Cat. No. W593) for the NX Unit power supply system.

NX Units Model

NX-PF Additional

I/O Power Supply

Unit required

Digital Input Units

NX-ID3317 Yes

NX-ID3343 Yes

NX-ID3344 Yes

NX-ID3417 Yes

NX-ID3443 Yes

NX-ID3444 Yes

NX-ID4342 Yes

NX-ID4442 Yes

NX-ID5342 Yes

NX-ID5442 Yes

NX-ID5142-1 No

NX-ID5142-5 No

NX-ID6142-5 No

NX-ID6142-6 No

NX-IA3117 No

Digital output Units

NX-OD2154 Yes

NX-OD2258 Yes

NX-OD3121 Yes

NX-OD3153 Yes

NX-OD3256 Yes

NX-OD3257 Yes

NX-OD3268 No

NX-OD4121 Yes

NX-OD4256 Yes

NX-OD5121 Yes

NX-OD5256 Yes

NX-OD5121-1 No

NX-OD5256-1 No

NX-OD5121-5 No

NX-OD5256-5 No

NX-OD6121-5 No

NX-OD6256-5 No

NX-OD6121-6 No

NX-OC2633 No

NX-OC2733 No

NX-OC4633 No

Digital Mixed I/O

Units

NX-MD6121-5 No

NX-MD6256-5 No

NX-MD6121-6 No

High-speed Analog

Input Units

NX-HAD401 Yes

NX-HAD402 Yes

Analog Input Units

NX-AD2603 Yes

NX-AD2604 No

NX-AD2608 No

NX-AD3603 Yes

NX-AD3604 No

NX-AD3608 No

NX-AD4603 Yes

NX-AD4604 No

NX-AD4608 No

NX-AD2203 Yes

NX-AD2204 No

NX-AD2208 No

NX-AD3203 Yes

NX-AD3204 No

NX-AD3208 No

NX-AD4203 Yes

NX-AD4204 No

NX-AD4208 No

NX Units Model

NX-PF Additional

I/O Power Supply

Unit required

Analog Output Units

NX-DA2603 Yes

NX-DA2605 Yes

NX-DA3603 Yes

NX-DA3605 Yes

NX-DA2203 Yes

NX-DA2205 Yes

NX-DA3203 Yes

NX-DA3205 Yes

Temperature

Control Units

NX-TC2405 Yes

NX-TC2406 Yes

NX-TC2407 Yes

NX-TC2408 Yes

NX-TC3405 Yes

NX-TC3406 Yes

NX-TC3407 Yes

NX-TC3408 Yes

Temperature Input

Units

NX-TS2101 No

NX-TS3101 No

NX-TS2102 No

NX-TS3102 No

NX-TS2104 No

NX-TS3104 No

NX-TS2201 No

NX-TS3201 No

NX-TS2202 No

NX-TS3202 No

NX-TS2204 No

NX-TS3204 No

Heater Burnout

Detection Units

NX-HB3101 Yes

NX-HB3201 Yes

Load Cell Input Unit NX-RS1201 No

Position interface:

Incremental

Encoder Input Units

NX-EC0112 Yes

NX-EC0122 Yes

NX-EC0132 Yes

NX-EC0142 Yes

NX-EC0212 Yes

NX-EC0222 Yes

Position interface:

SSI Input Units

NX-ECS112 Yes

NX-ECS212 Yes

Position interface:

Pulse Output Units

NX-PG0112 Yes

NX-PG0122 Yes

NX-PG0232-5 No

NX-PG0242-5 No

NX-PG0332-5 No

NX-PG0342-5 No

Communications

Interface Units

NX-CIF101 No

NX-CIF105 No

NX-CIF210 No

RFID Units

NX-V680C1 Yes

NX-V680C2 Yes

IO-Link Master Unit NX-ILM400 Yes

Safety Input Units

NX-SIH400 Yes

NX-SID800 Yes

Safety Output Units

NX-SOH200 Yes

NX-SOD400 Yes
