5．Applicable Devices and Device Configuration
7
Precautions for Correct Use
The connection line of EtherCAT communications cannot be shared with other Ethernet
networks.
Do not use devices for Ethernet such as an Ethernet switch.
Use an Ethernet cable (double shielding with aluminum tape and braiding) of Category 5 or
higher, and use a shielded connector of Category 5 or higher.
Connect the cable shield to the connector hood at both ends of the cable.
Precautions for Correct Use
Update Sysmac Studio, CX-ConfiguratorFDT and IODD DTM Configurator to the versions
specified on the previous page or to higher versions. If you use a version higher than the one
specified, the procedures and related screenshots described in Section 7. and the
subsequent sections may not be applicable. In that case, use the equivalent procedures
described in this guide by referring to the Sysmac Studio Version 1 Operation Manual (Cat.
No. W504) and the CX-ConfiguratorFDT Online Help.
Precautions for Correct Use
To connect the Signal Tower to the NX-series IO-Link Master Unit, you need a communication
cable with a connector on one end. For information on the connector specifications of the
Signal Tower, refer to the IO-Link Signal Tower TYPE LR6-IL Complete Operation Manual
(GA0001002).
Additional Information
For information on the specifications of Ethernet cables and network wiring, refer to Section
4. EtherCAT Network Wiring of the NJ/NX-series CPU Unit Built-in EtherCAT® Port User's
For information on the power supply specifications of the Controller, refer to the NX-series
NX102 CPU Unit Hardware User's Manual (Cat. No. W593).
Refer to the NX-series EtherCAT® Coupler Unit User's Manual (Cat. No. W519) for
information on the unit power supply specifications of the Slave Terminal and the power
supply specifications for I/O.
