System Configuration
System Configuration
(B) EtherNet/IP scanner
(I) Communications cable
EtherNet/IP cable
(M) EDS files
EtherNet/IP port
(H) Ethernet switch
(N) Support Software
for the Controller
(L) Network Configurator
(C) EtherNet/IP adapter:
NXR-series EtherNet/IP IO-Link
Master Unit
(F) IO-Link device:
NXR-series IO-Link I/O Hub
(G) Non-IO-Link connected External Device
(A) Controller
(J) CX-ConfiguratorFDT
(E) Output power supply
(D) Unit/input power supply
Through-wiring for power supplies
(K) IODD files
(G) Non-IO-Link connected External Device
