NXR-ILM08C-EIT
5
EtherNet/IP Communications Cables
Ethernet communications cables to connect the IO-Link master unit.
Connection Cables between IO-Link Master Unit and EtherNet/IP Scanner with RJ45 Connectors
Connection Cables between IO-Link Master Units
Power Supply Cables
Power supply cables to connect the IO-Link master unit
Name and appearance Manufacturer Specification
No. of cable
conductors
Connector
Cable
connection
direction
Cable
length
Model
Industrial Ethernet Connectors
with Cable
HARTING K.K.
M12 plug
(D-coding, male)
to RJ45
4
Screw
connector
Straight/
straight
0.5 m 72MDm4Rm4005K
1 m 72MDm4Rm4010K
2 m 72MDm4Rm4020K
3 m 72MDm4Rm4030K
5 m 72MDm4Rm4050K
10 m 72MDm4Rm4100K
Name and appearance Manufacturer Specification
No. of cable
conductors
Connector
Cable
connection
direction
Cable
length
Model
Industrial Ethernet Connectors
with Cable
HARTING K.K.
M12 plug
(D-coding, male)
to M12 plug
(D-coding, male)
4
Screw
connector
Straight/
straight
0.5 m 72MDm4MDm4005K
1 m 72MDm4MDm4010K
2 m 72MDm4MDm4020K
3 m 72MDm4MDm4030K
5 m 72MDm4MDm4050K
10 m 72MDm4MDm4100K
Name and appearance Manufacturer Specification
No. of cable
conductors
Connector
Cable
connection
direction
Cable
length
Model
Connector with Cable
(Socket on One End, Straight)
HARTING K.K.
7/8 inch socket
(female) to
discrete wire
4
Screw
connector
Straight
1 m 72MNf4010
2 m 72MNf4020
5 m 72MNf4050
10 m 72MNf4100
Connector with Cable
(Socket on One End, Right-
angle)
Right-angle
1 m 72MNfL4010
2 m 72MNfL4020
5 m 72MNfL4050
10 m 72MNfL4100
Connectors with Cable
(Socket on One End, Plug on
Other End, Straight)
7/8 inch socket
(female) to
7/8 inch plug
(male)
4
Screw
connector
Straight
1 m 72MNf4MNm4010
2 m 72MNf4MNm4020
5 m 72MNf4MNm4050
10 m 72MNf4MNm4100
Connectors with Cable
(Socket on One End, Plug on
Other End, Right-angle)
Right-angle
1 m 72MNfL4MNmL4010
2 m 72MNfL4MNmL4020
5 m 72MNfL4MNmL4050
10 m 72MNfL4MNmL4100
Contact HARTING K.K. for details.
