A-9
A-1 Object List
OMNUC G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
A
Appendix
Index Sub Name Size
Data
attribute
PDO map
Saving to
EEPROM
3204 hex 0 hex Notch 2 Frequency Setting 2 bytes (INT16) B Not possible. Possible.
3205 hex 0 hex Notch 2 Width Setting 2 bytes (INT16) B Not possible. Possible.
3206 hex 0 hex Notch 2 Depth Setting 2 bytes (INT16) B Not possible. Possible.
3207 hex 0 hex Notch 3 Frequency Setting 2 bytes (INT16) B Not possible. Possible.
3208 hex 0 hex Notch 3 Width Setting 2 bytes (INT16) B Not possible. Possible.
3209 hex 0 hex Notch 3 Depth Setting 2 bytes (INT16) B Not possible. Possible.
3210 hex 0 hex Notch 4 Frequency Setting 2 bytes (INT16) B Not possible. Possible.
3211 hex 0 hex Notch 4 Width Setting 2 bytes (INT16) B Not possible. Possible.
3212 hex 0 hex Notch 4 Depth Setting 2 bytes (INT16) B Not possible. Possible.
3213 hex 0 hex Damping Filter Selection 2 bytes (INT16) B Not possible. Possible.
3214 hex 0 hex Damping Frequency 1 2 bytes (INT16) B Not possible. Possible.
3215 hex 0 hex Damping Filter 1 Setting 2 bytes (INT16) B Not possible. Possible.
3216 hex 0 hex Damping Frequency 2 2 bytes (INT16) B Not possible. Possible.
3217 hex 0 hex Damping Filter 2 Setting 2 bytes (INT16) B Not possible. Possible.
3218 hex 0 hex Damping Frequency 3 2 bytes (INT16) B Not possible. Possible.
3219 hex 0 hex Damping Filter 3 Setting 2 bytes (INT16) B Not possible. Possible.
3220 hex 0 hex Damping Frequency 4 2 bytes (INT16) B Not possible. Possible.
3221 hex 0 hex Damping Filter 4 Setting 2 bytes (INT16) B Not possible. Possible.
3222 hex 0 hex Position Command Filter Time Constant 2 bytes (INT16) B Not possible. Possible.
3323 hex 0 hex External Feedback Pulse Type Selection 2 bytes (INT16) R Not possible. Possible.
3324 hex 0 hex External Feedback Pulse Dividing Numerator 4 bytes (INT32) R Not possible. Possible.
3325 hex 0 hex
External Feedback Pulse Dividing
Denominator
4 bytes (INT32) R Not possible. Possible.
3326 hex 0 hex External Feedback Pulse Direction Switching 2 bytes (INT16) R Not possible. Possible.
3327 hex 0 hex External Feedback Pulse Phase-Z Setting 2 bytes (INT16) R Not possible. Possible.
3328 hex 0 hex
Hybrid Following Error Counter Overflow
Level
4 bytes (INT32) C Not possible. Possible.
3329 hex 0 hex Hybrid Following Error Counter Reset 2 bytes (INT16) C Not possible. Possible.
3400 hex 0 hex Input Signal Selection 1 4 bytes (INT32) C Not possible. Possible.
3401 hex 0 hex Input Signal Selection 2 4 bytes (INT32) C Not possible. Possible.
3402 hex 0 hex Input Signal Selection 3 4 bytes (INT32) C Not possible. Possible.
3403 hex 0 hex Input Signal Selection 4 4 bytes (INT32) C Not possible. Possible.
3404 hex 0 hex Input Signal Selection 5 4 bytes (INT32) C Not possible. Possible.
3405 hex 0 hex Input Signal Selection 6 4 bytes (INT32) C Not possible. Possible.
3406 hex 0 hex Input Signal Selection 7 4 bytes (INT32) C Not possible. Possible.
