Omron R88D-KT Series User Manual

3-132
3-5 Servo Relay Units and Cable Specifications
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
3
Specifications
XW2B-40J6-9A
This Servo Relay Unit connects to the following OMRON Programmable Controllers.
Dimensions
 Terminal block pitch: 7.62 mm
 CJ1M-CPU21/-CPU22/-CPU23 (for 2
axes)
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
29.5
7
3.5 180 3.5
7
45
15.5
0
20
19
39
20.5
42.8
2
Y-axis drive sideX-axis drive sideCJ1M-CPU21/22/23 side
(46)
2-φ3.5
