Omron R88D-KT50F User Manual

4-14
4-2 Wiring
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
4
System Design
R88D-KT06F/-KT10F/-KT15F/-KT20F
Noise filter (*1)
3-phase 380 to 480 VAC, 50/60 Hz
Main circuit contactor (*1)
Servo alarm display
24 VDC
OMNUC G5-series
AC Servo Drive
User-side
control
device
24 VDC
24 VDC
Control cables
OMNUC G5-series
AC Servomotor
Encoder cables
Power cables
24 VDC
(*3)
(*2)
(*4)
Regeneration
Resistor
Ground to 10 Ω or less
Surge suppressor (*1)
Main circuit power supply
RT
NFB
S
123
456
E
NF
PL
24 V
0 V
L1
L2
L3
ALMCOM
/ALM37
36
CN1
X
11
10
OUTM1
(BKIR)
OUTM1
COM
XB
W
V
U
B
E
M
CN2
CN1
CN1
B1
B3
B2
CNB
CND
CNC
CNA
X
XB
X
1MC
OFF ON X
1MC
1MC
Reactor
Ground to 10 Ω or less.
*1. Recommended products are listed in 4-3
Wiring Conforming to EMC Directives.
*2. Recommended relay: MY relay by
OMRON (24-V)
For example, MY2 relay by OMRON can
be used with all G5-series motors with
brakes because its rated induction load is
2 A (24 VDC).
*3. There is no polarity on the brakes.
*4. The Built-in Regeneration Resistor
(KT06F to KT20F) connects B2 and B3.
When the amount of regeneration is
large, remove the connection between
B2 and B3 and connect the Regeneration
Resistor between B1 and B2.
