2-17
2-3 Standard Model Tables
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
2
Standard Models and External Dimensions
Note 1.: Different connectors are used for the motor power and the brake on 100-V and 200-V, 3,000-r/
min Servomotors of 50 to 750 W and Servomotors of 6 to 15 kW. When using a Servomotor with
a brake, two cables are required: a Power Cable without Brake and a Brake Cable.
Note 2.: For non-flexible power cables for Servomotors of 11 or 15 kW, refer to 4-2 Wiring (P. 4-7) and
make your own cable.
Brake Cables (Global Non-Flexible Cables)
For 2,000-r/min Servomotors of 7.5 kW
For 1,000-r/min Servomotors of 6 kW
3 m R88A-CAGE003S -
5 m R88A-CAGE005S -
10 m R88A-CAGE010S -
15 m R88A-CAGE015S -
20 m R88A-CAGE020S -
30 m R88A-CAGE030S -
40 m R88A-CAGE040S -
50 m R88A-CAGE050S -
Specifications
Model
For motor without
brake
For motor with brake
Specifications Model
[100 V and 200 V]
For 3,000-r/min Servomotors of 50 to 750 W
3 m R88A-CAKA003B
5 m R88A-CAKA005B
10 m R88A-CAKA010B
15 m R88A-CAKA015B
20 m R88A-CAKA020B
30 m R88A-CAKA030B
40 m R88A-CAKA040B
50 m R88A-CAKA050B
For 1,500-r/min Servomotors of 7.5 to 15 kW
For 1,000-r/min Servomotors of 6 kW
3 m R88A-CAGE003B
5 m R88A-CAGE005B
10 m R88A-CAGE010B
15 m R88A-CAGE015B
20 m R88A-CAGE020B
30 m R88A-CAGE030B
40 m R88A-CAGE040B
50 m R88A-CAGE050B
