2-6
• Power Cable for 1,500-r/min Servomotors
Specifications Model
p
Without brake With brake
450 to
1 3 kW
3 m R88A-CAWC003S R88A-CAWC003B
1.3 kW
5 m R88A-CAWC005S R88A-CAWC005B
10 m R88A-CAWC010S R88A-CAWC010B
15 m R88A-CAWC015S R88A-CAWC015B
20 m R88A-CAWC020S R88A-CAWC020B
30 m R88A-CAWC030S R88A-CAWC030B
40 m R88A-CAWC040S R88A-CAWC040B
50 m R88A-CAWC050S R88A-CAWC050B
1.8 to
4 4 kW
3 m R88A-CAWD003S R88A-CAWD003B
4.4 kW
5 m R88A-CAWD005S R88A-CAWD005B
10 m R88A-CAWD010S R88A-CAWD010B
15 m R88A-CAWD015S R88A-CAWD015B
20 m R88A-CAWD020S R88A-CAWD020B
30 m R88A-CAWD030S R88A-CAWD030B
40 m R88A-CAWD040S R88A-CAWD040B
50 m R88A-CAWD050S R88A-CAWD050B
5.5 kW
(S t
3 m R88A-CAWE003S R88A-CAWE003B
(See note
1.)
5 m R88A-CAWE005S R88A-CAWE005B
1
.
)
10 m R88A-CAWE010S R88A-CAWE010B
15 m R88A-CAWE015S R88A-CAWE015B
20 m R88A-CAWE020S R88A-CAWE020B
30 m R88A-CAWE030S R88A-CAWE030B
40 m R88A-CAWE040S R88A-CAWE040B
50 m R88A-CAWE050S R88A-CAWE050B
7.5 to
11 kW
3 m R88A-CAWF003S R88A-CAWE003B
11 kW
(See note
5 m R88A-CAWF005S R88A-CAWE005B
(See note
1.)
10 m R88A-CAWF010S R88A-CAWE010B
)
15 m R88A-CAWF015S R88A-CAWE015B
20 m R88A-CAWF020S R88A-CAWE020B
30 m R88A-CAWF030S R88A-CAWE030B
40 m R88A-CAWF040S R88A-CAWE040B
50 m R88A-CAWF050S R88A-CAWE050B
Note 1. For Servomotors of 5.5 kW and higher, there are sepa-
rate connectors for power and brakes. Therefore, when
a Servomotor with a brake is used, it will require both a
Power Cable for a Servomotor without a brake (i.e.,
R88A-CAWEjS or R88A-CAWFjS) and a Power
Cable for a Servomotor with a brake (i.e., R88A-CAWE-
jB). The Power Cable for a Servomotor of 5.5 kW or
higher with a Brake is for brake line wiring only (2-core).
Note 2. For details on preparing Power Cable for 15-kW Servo-
motors, refer to Power Cable for 1,500-r/min Servomo-
tors under 3-2-3 Terminal Block Wiring.
H Encoder Cables for Robot Cables (For
Incremental or Absolute Encoders)
Specifications Model
For 3,000-r/min
St
30 to
750 W
3 m R88A-CRWA003CR
,/
Servomotors 750 W
5 m R88A-CRWA005CR
10 m R88A-CRWA010CR
15 m R88A-CRWA015CR
20 m R88A-CRWA020CR
30 m R88A-CRWA030CR
40 m R88A-CRWA040CR
50 m R88A-CRWA050CR
1 to 5 kW
3 m R88A-CRWB003NR
5 m R88A-CRWB005NR
10 m R88A-CRWB010NR
15 m R88A-CRWB015NR
20 m R88A-CRWB020NR
30 m R88A-CRWB030NR
40 m R88A-CRWB040NR
50 m R88A-CRWB050NR
For 3,000-r/min
Fl t t l
100 W to
1 5 kW
3 m R88A-CRWA003CR
,/
Flat-style
Servomotors
1.5 kW
5 m R88A-CRWA005CR
Servomotors
10 m R88A-CRWA010CR
15 m R88A-CRWA015CR
20 m R88A-CRWA020CR
30 m R88A-CRWA030CR
40 m R88A-CRWA040CR
50 m R88A-CRWA050CR
For 1,000-r/min
St
300 W to
5 5 kW
3 m R88A-CRWB003NR
,/
Servomotors
F 1 500 / i
5.5 kW
450 W t
5 m R88A-CRWB005NR
For 1,500-r/min
Servomotors
450 W to
15 kW
10 m R88A-CRWB010NR
Ser
v
omotors
15 kW
15 m R88A-CRWB015NR
20 m R88A-CRWB020NR
30 m R88A-CRWB030NR
40 m R88A-CRWB040NR
50 m R88A-CRWB050NR
Standard Models and Specifications Chapter 2
