Omron S82K

S82K
S82K
11
S82K-09024 (90 W)
S82K-10024 (100 W)
Fuse (5 A)
Noise filter
Inrush current
protection circuit
Rectifier
Drive control
circuit
Photocoupler
AC (L)
AC (N)
Rectifier
– V
+ V
Overload
alarm
circuit
Detector
100 or 200 V
Selectable
terminals
(See Note.)
Note: Use the short bar to short-circuit terminals 7 and 8 to select 100 to 120 VAC and remove the short bar to select
200 to 240 VAC.
DC LOW
Undervoltage
alarm
indicator/output
S82K-24024 (240 W)
– V
+ V
Fuse (5 A)
Noise filter
Inrush current
protection circuit
Drive control
circuit
DC
OUTPUT
Overvoltage protection circuitry (see note 1)
Photocoupler
INPUT
AC (L)
AC (N)
Overload alarm
circuit
Rectifying and
smoothing circuit
Overvoltage
alarm circuit
Detector
GR
Rectifier
DC LOW
Undervoltage
alarm
indicator/output
(See Note 3.)
Note: 1. The overvoltage protection circuitry is available in the S82K-24024T only.
2. Use the short bar to short-circuit terminals 7 and 8 to select 100 to 120 VAC and remove the short bar to select
200 to 230 VAC.
3. The undervoltage alarm indicator is available in the S82K-24024T.
100 or 200 V
Selectable
terminals
(See Note 2.)
S82K-P24024 (240 W)
– V
+ V
Fuse (8 A)
Noise filter
Inrush current
protection circuit
Drive control
circuit
DC
OUTPUT
INPUT
AC (L)
AC (N)
Overload alarm
circuit
Rectifying and
smoothing circuit
Detector
GR
Rectifier
Harmonic current
emission control
Smoothing
Photocoupler
