Omron S8VK-G48024

S8VS
14
Alarm Output Connections
Noise filter
Drive circuit
AC (L)
INPUT
AC (N)
Photocoupler
DC LOW
Yrs/kh
Switch
S8VS-48024A/B
Fuse 12A
Rectifier
Smoothing
circuit
Inrush
current
protection
circuit
Harmonic current
suppression
(power factor
improvement)
Auxiliary power
supply circuit
Rectifier/
smoothing
circuit
Control
circuit
Rectifier/
smoothing circuit
Voltage
detection circuit
Overvoltage
detection circuit
Overcurrent
circuit
Current
detection circuit
Arithmetic
operation
circuit
Display
circuit
+V
+V
+V
−V
DC OUTPUT
−V
−V
S8VS-48024-@ (480 W)
S8VS-48024A-@ (480 W)
S8VS-48024B-@ (480 W)
90, 120, 180, and 240 W (Sinking type)
11
12
13
Undervoltage
Undervoltage
Maintenance
forecast time or
total run time
Maintenance
forecast time or
total run time
Common
90, 120, 180, and 240 W (Sourcing type)
13
11
12
Common
Undervoltage
Maintenance
forecast time or
total run time
Undervoltage
Maintenance
forecast time or
total run time
480 W
11
12
13
14
Undervoltage
Maintenance
forecast time or
total run time
Undervoltage
Maintenance
forecast time or
total run time
