Omron S8VS Series User Manual

S8VS
S8VS-24024-@ (240 W)
DC OUTPUT
INPUT
Photocoupler
Rectifier/smoothing circuit
+V
−V
Fuse
8.0 A
AC (L)
AC (N)
Rectifier
Voltage
detection circuit
Noise filter
Drive control
circuit
Overvoltage
detection circuit
Inrush current
protection
circuit
Smooth-
ing
circuit
Harmonic
current
suppression
Overcurrent
detection circuit
S8VS-48024-@ (480 W)
S8VS-48024A-@ (480 W)
S8VS-48024B-@ (480 W)
Drive circuit
Auxiliary power
supply circuit
Control
circuit
+V
+V
+V
−V
DC OUTPUT
Fuse 12A
AC (L)
INPUT
AC (N)
DC LOW
Yrs/kh
Sinking/Sourcing
S8VS-48024A/B
−V
−V
Noise filter
Rectifier
Rectifier/
smoothing circuit
Rectifier/
smoothing
circuit
Photocoupler
Display
circuit
Switch
Harmonic
current
suppression
Smoothing
circuit
Inrush
current
protection
circuit
Voltage
detection circuit
Overvoltage
detection circuit
Overcurrent
circuit
Current
detection circuit
Arithmetic
operation
circuit
13

Omron S8VS Series Specifications

General

Output Power	60 W, 120 W, 240 W
Mounting	DIN Rail Mounting
Protection	Overcurrent protection, Overvoltage protection
Safety Standards	UL508, EN50178
Dimensions	22.5 x 90 x 100 mm
Output Voltage	24 VDC
