SS
SS
170
Specifications
Ratings
Item
Resistive load
Model Rated voltage
SS-10 250 VAC 10.1 A
SS-5 125 VAC
250 VAC
5 A
3 A
SS-01
125 VAC 0.1 A
30 VDC 0.1 A
Note: The ratings values apply under the following test conditions:
Ambient temperature: 20±2°C
Ambient humidity: 65±5%
Operating frequency: 30 operations/min
Switching Capacity per Load (Reference Values)
Voltage
SS-10, SS-5 SS-01
Non-inductive load Inductive load Non-inductive load
Resistive load Lamp load Inductive load Motor load Resistive load
NC NO NC NO NC NO NC NO NC NO
125 VAC
5 (10.1) A
(see note 1)
1.5 A 0.7 A 3 A 2.5 A 1.3 A 0.1 A
250 VAC
3 (10.1) A
(see note 1)
1 A 0.5 A 2 A 1.5 A 0.8 A ---
8 VDC 5 (10.1) A
(see note 1)
2 A 5 A 4 A 3 A 0.1 A
14 VDC 5 (10.1) A
(see note 1)
2 A 4 A 4 A 3 A 0.1 A
30 VDC 4 A 2 A 3 A 3 A 3 A 0.1 A
125 VDC 0.4 A 0.05 A 0.4 A 0.4 A 0.05 A ---
250 VDC 0.2 A 0.03 A 0.2 A 0.2 A 0.03 A ---
Note: 1. Data in parentheses apply to the SS-10 models only.
2. The above values are for the steady-state current.
3. Inductive load has a power factor of 0.4 min. (AC) and a time constant of 7 ms max. (DC). The inductive load rating of SS-10 is the
same as that of SS-5.
4. Lamp load has an inrush current of 10 times the steady-state current.
5. Motor load has an inrush current of 6 times the steady-state current.
6. If the Switch is used in a DC circuit and is subjected to a surge, connect a surge suppressor across the Switch.
