Omron STC-HD203 Series - Mechanical Specifications; Stc-Hd203 Dv Stc-Hd203 Dv-Cs; Stc-Hd203 Sdi Stc-Hd203 Sdi-Cs; Environmental Specifications

No. 13S054-10
STC-HD203DV / STC-HD203DV-CS / STC-HD203SDI / STC-HD203SDI-CS
Product Specifications and Users Guide
11/78
4.3 Mechanical Specifications
STC-HD203DV / STC-HD203DV-CS
(*1) Excluding connectors
(*2) Recommend lens: More than F2.8 (Close side)
(*3) Please use 2.1mm plug for DC power plug
STC-HD203SDI / STC-HD203SDI-CS
(*1) Excluding connectors
(*2) Recommend lens: More than F2.8 (Close side)
(*3) Please use 2.1mm plug for DC power plug
4.4 Environmental Specifications
Model Number STC-HD203DV STC-HD203DV-CS
Dimensions 40 (W) x 40 (H) x 48.9 (D) mm (*1) 40 (W) x 40 (H) x 43.9 (D) mm (*1)
Optical Filter IR cut filter with OPLF
Material Aluminum (AC)
Lens Mount (*2) C Mount CS Mount
Dimensions Internal
Connectors
Video Output Connector: HDMI Connector
Power Input Connector: DC power jack (*3)
Remote Control / UART Communication Connector: 3.5Φ Stereo Jack
Camera Mount Screws
Two 1/4” Tripod screw holes: (One on top and bottom plate)
Eight M4 screws holes: (Four on top and bottom plate)
Weight Approximately 116 g
Model Number STC-HD203SDI STC-HD203SDI-CS
Dimensions 40 (W) x 40 (H) x 48.9 (D) mm (*1) 40 (W) x 40 (H) x 43.9 (D) mm (*1)
Optical Filter IR cut filter with OPLF
Material Aluminum (AC)
Lens Mount (*2) C Mount CS Mount
Dimensions Internal
Connectors
Video Output Connector: BNC Connector
Power Input Connector: DC power jack (*3)
Remote Control / UART Communication Connector: 3.5Φ Stereo Jack
Camera Mount Screws
Two 1/4” Tripod screw holes: (One on top and bottom plate)
Eight M4 screws holes: (Four on top and bottom plate)
Weight Approximately 136 g
Model Number STC-HD203DV / STC-HD203DV-CS STC-HD203SDI / STC-HD203SDI-CS
Operational Temperature / Humidity Environmental Temperature: 0 to +40 deg. C,
Environmental Humidity: 0 to 85 %RH (No condensation)
Storage Temperature / Humidity Environmental Temperature: -30 to +65 deg. C,
Environmental Humidity: 0 to 85 %RH (No condensation)
Vibration 20 Hz to 200 Hz to 20 Hz (5 min. / cycle), acceleration 10 G, XYZ 3 directions 30 min. each
Shock Acceleration 38 G, half amplitude 6 mseconds, XYZ 3 directions 3 times each
Standard Compliancy EMS: EN61000-6-2, EMI: EN55011 (Class A)
RoHS RoHS compliance
