Omron STC-HD203 Series - Byte Consecutive Command

No. 13S054-10
STC-HD203DV / STC-HD203DV-CS / STC-HD203SDI / STC-HD203SDI-CS
Product Specifications and Users Guide
59/78
2 Byte consecutive Command
Note: The data have to send as follow order D15-D8, D7-D0.
Functions D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4
Display Character
Control Command
1 1 RV R G B BL 0 C7 C6 C5 C4
Functions D3 D2 D1 D0
Display Character
Control Command
C3 C2 C1 C0
Display Character Control Command
Set the Writing character data, character color, blink data into Video RAM address.
This command is 2 Byte consecutive command, if more than 2 consecutive character writing are required, just send only lower
8bits (C7 to C0). Write address will be increased automatically.
When character control exits, please send 0xFF (End code of 2 Byte consecutive command).
RV: Character color reverse specification (0: OFF, 1: ON）
RGB: Character Color (0: Black, 1: Blue, 2: Green, 3: Cyan, 4: Red, 5: Magenta, 6: Yellow, 7: White)
BL: Character blinks (0: Blink, 1: Not Blink)
C7-C0: Character code (please refer to the Character table as below)
C7 - C0 Character C7 - C0 Character C7 - C0 Character C7 - C0 Character
000 sp 019 9 032 R 04B k
001 ! 01A : 033 S 04C l
002 “ 01B ; 034 T 04D m
003 # 01C < 035 U 04E n
004 $ 01D = 036 V 04F o
005 % 01E > 037 W 050 p
006 & 01F ? 038 X 051 q
007 ‘ 020 > fill 039 Y 052 r
008 ( 021 A 03A Z 053 s
009 ) 022 B 03B [ 054 t
00A * 023 C 03C ¥ 055 u
00B + 024 D 03D ] 056 v
00C , 025 E 03E < fill 057 w
00D - 026 F 03F △ 058 x
00E . 027 G 040 ▽ 059 y
00F / 028 H 041 a 05A z
010 0 029 I 042 b 05B ・
011 1 02A J 043 c 05C ・・
012 2 02B K 044 d 05D ・・・
013 3 02C L 045 e 05E ～
014 4 02D M 046 f 05F ◆
015 5 02E N 047 g 060 ×
016 6 02F O 048 h 061 ÷
017 7 030 P 049 i 0FF 2 byte
control finish
018 8 031 Q 04A j
