7.4 The uCOM register mapping list
* Please do not change “Reserved data”.
Address
7
6
5
4
3
2
1
0
Descriptions Default
000 X
X
X
User Preset
DSP register setting can save on eight Preset areas.
* When this vale saves to the EEPRM, camera starts with saved
DSP mode at power up.
0: Preset 0 1: Preset 1
2: Preset 2 3: Preset 3
4: Preset 4 5: Preset 5
6: Preset 6 7: Preset 7
0
X
X
X
X
X
Reserved -
001 -
00D
X
X
X
X
X
X
X
X
Reserved
00E X
Control by the "Push button" on the side of the camera
0: Disable 1: Enable
1
X
X
X
X
X
X
X
Reserved -
00F X
X
UART baud rate
0: 9,600 bps 1: 19,200 bps
2: 38,400 bps 3: 9,600 bps
* Change to lower baud rate when communication error is
occurred.
2
X
X
X
X
Reserved -
X
Return data and data length of UART write command
0: Return data is including exact same data of write command.
1: Return data is excluding data of write command, and data
length is 0.
0
X
UART check sum
0: Disable 1: Enable
* When selecting disable, camera process command even check
sum of send command is not mach.
1
