No. 13S054-10
STC-HD203DV / STC-HD203DV-CS / STC-HD203SDI / STC-HD203SDI-CS
Product Specifications and Users Guide
39/78
Address
7
6
5
4
3
2
1
0
Descriptions Default
010 X
X
X
X
X
X
X
X
User defined color 0 Red 255
011 X
X
X
X
X
X
X
X
User defined color 0 Green 128
012 X
X
X
X
X
X
X
X
User defined color 0 Blue 0
013 X
X
X
X
X
X
X
X
User defined color 1 Red 255
014 X
X
X
X
X
X
X
X
User defined color 1 Green 0
015 X
X
X
X
X
X
X
X
User defined color 1 Blue 128
016 X
X
X
X
X
X
X
X
User defined color 2 Red 128
017 X
X
X
X
X
X
X
X
User defined color 2 Green 255
018 X
X
X
X
X
X
X
X
User defined color 2 Blue 0
019 X
X
X
X
X
X
X
X
User defined color 3 Red 0
01A X
X
X
X
X
X
X
X
User defined color 3 Green 255
01B X
X
X
X
X
X
X
X
User defined color 3 Blue 128
01C X
X
X
X
X
X
X
X
User defined color 4 Red 128
01D X
X
X
X
X
X
X
X
User defined color 4 Green 0
01E X
X
X
X
X
X
X
X
User defined color 4 Blue 255
01F X
X
X
X
X
X
X
X
User defined color 5 Red 0
020 X
X
X
X
X
X
X
X
User defined color 5 Green 128
021 X
X
X
X
X
X
X
X
User defined color 5 Blue 255
022 X
X
X
X
X
X
X
X
User defined color 6 Red 128
023 X
X
X
X
X
X
X
X
User defined color 6 Green 128
024 X
X
X
X
X
X
X
X
User defined color 6 Blue 128
025 X
X
X
X
X
X
X
X
User defined color 7 Red 255
026 X
X
X
X
X
X
X
X
User defined color 7 Green 207
027 X
X
X
X
X
X
X
X
User defined color 7 Blue 0
028 X
X
X
X
Control button (Decrease page) for display menu
9: WB
10: SW A 11: SW B
12: SW C 13: SW D
14: SW E 15: SW F
0
X
X
X
X
Control button (Increase page) for display menu
9: WB
10: SW A 11: SW B
12: SW C 13: SW D
14: SW E 15: SW F
9
029 X
X
X
X
Menu: down
Selectable Parameters are same as Address 028
15
X
X
X
X
Menu: up
Selectable Parameters are same as Address 028
11
02A X
X
X
X
Menu: right
Selectable Parameters are same as Address 028
14
X
X
X
X
Menu: left
Selectable Parameters are same as Address 028
12
02B X
X
X
X
Menu: return
Selectable Parameters are same as Address 028
10
X
X
X
X
Menu: enter
Selectable Parameters are same as Address 028
13
